Denon S-5BD

Description

Combining the latest high definition audio technologies from Denon’s renowned line of versatile A/V receivers along with our exclusive center-mounted Blu-ray disc player drive mechanism, the S-5BD provides superlative performance and unparalleled ease of use. The audio section is packed with the latest high definition surround sound decoders, including Dolby TrueHD and DTS-HD Master Audio. Setup is a breeze thanks to automatic configuration via Audyssey MultEQ room acoustic measurement and correction system, which detects the quantity and type of speakers, and provides precise tailoring of critical audio parameters for pristine sound quality (measurement microphone included). Audyssey Dynamic EQ provides rich tonal balance at all volume levels, and Audyssey Dynamic Volume smoothes out jarring volume peaks, such as TV commercial interruptions. The elegant front panel features dual side wing doors, which open to reveal convenient connections, including one HDMI input, an SD memory card slot, and a USB port for direct iPod connection. When closed, the wings conceal wires for a clean, elegant look. The Blu-ray player incorporates the latest features, including BD-Live support via the Ethernet port, and the S-5BD features support for Denon’s versatile iPod docks, including the ASD-51N and ASD-51W.

Features:

Amplifier

• Stereo RMS Power: 75W per channel x 2
• Surround RMS Power: 75W per channel x 5, into 4 Ohms
• THD: All channels rated at 0.7%
• Impedance: Speaker: 4-16 Ohms (Front, center, surround), Input: 150 mV/47 Ohms (Analog audio)
• No. of Channels: 5.1, 7.1 with amplification

Audio Processing

• Dolby Digital: Yes
• Dolby Digital EX: Yes
• Dolby Pro Logic II: Yes
• DTS: DTS, DTS 96/24
• DTS ES: Yes
• DTS Neo:6: Yes
• THX Surround EX: No
• THX Certified: No

Convenience

• Speaker Selector: Yes
• Multi Room/Source: 2 / 2

Tuner

• Frequency Range: AM: 520-1710 kHz, FM: 87.5-107.9 MHz
• Sensitivity: AM: 20 uV, FM: 1.5 uV / 75 Ohms (14.7 dBf)
• Separation: FM: 35 dB (1 kHz)
• Remote Control: IR Wireless, Batteries: R6/AA x 2, Maximum external dimensions: 2.1 x 9.6 x .8" (52 x 243 x 21 mm), Weight including batteries: 0.4 lb (175 g)
• Input: HDMI 1.4 x 3, S-Video x 1, Analog audio x 2, Digital optical x 2, Digital coaxial x 1
• Output: HDMI 1.4 (repeater) x 1, Composite (for Zone 2) x 1, Analog Audio (for Zone 2) x 1, Analog Preout (2.1 ch, SBL/SBR/SW) x 1, Headphone Jack x 1
• Other Ports: FM Tuner Antenna x 1, AM Tuner Antenna x 1, USB x 1, SD Card x 1, Dock Control x 1, Ethernet x 1, Trigger x 1, RS-232C x 1, Remote In/Out x 1/ x 1

General

• Power Requirements: 120 V, 60 Hz
• Power Consumption: 110W, Standby: 0.3W
• Dimensions (WxHxD): Doors closed: 17.1 x 4.7 x 14.4" (434 x 119 x 365 mm), Doors open: 17.5 x 4.7 x 14.4" (445 x 119 x 365 mm)
• Weight: 17.2 lb (7.8 kg)
• Finish: Black
• Video Output :
• System: NTSC
• Playback Formats: BD-Video, DVD-Video, DVD-R, DVD-RW, DVD+R, DVD+RW, CD, CD-R, CD-RW
• For PC File: CD-R, CD-RW, DVD-R, DVD-RW
• Memory Card: SD memory card / SDHC memory card / mini SD card / micro SD card
