Chauvet Pro NOVASTAR MX40 PRO

NovaStar Protocol video driver.

The MX40 Pro stands as NovaStar™'s advanced 4K LED display controller, boasting a diverse array of input ports including HDMI 2.0, DP 1.2, and 12G-SDI. Complementing this are 20 Ethernet output ports alongside 4 cutting-edge 10G optical ports, designed to facilitate seamless data duplication across output channels. This controller seamlessly integrates with NovaStar's VMP screen configuration software and A10s Pro receiving cards, promising users an unparalleled experiential journey.

Within the MX40 Pro, you not only secure a top-tier video controller, but also harness the might of an integrated potent processor furnished with an inbuilt color adjustment mechanism. The prowess of true 12-bit color depth, HDR capabilities, elevated frame rates, and immersive 3D technologies lie readily accessible. Its color calibration feature faithfully reproduces and substitutes colors, further enriched by its offering of XR functionality, LED Image Booster, Dynamic Booster, and an array of additional features.

Chauvet Pro NOVASTAR MX40 PRO Features:

• Large loading capacity of up to 8.8 million pixels
• A perfect fit with NovaStar A10s Pro receiving cards and VMP software
• Controller & processor with color adjustment system

Chauvet Pro NOVASTAR MX40 PRO Specifications:

• Connectors:
• Inputs:
• (3) HDMI 2.0 In + Loop
• (1) DP 1.2
• (1) 12G-SDI In + Loop
• (1) Genlock In + Loop
• Outputs:
• (20) Ethernet outputs
• (4) 10G OPT outputs
• Control:
• TFT menu display
• (2) Ethernet ports
• Genlock In + Loop
• Power & Current:
• 100-240VAC, 50-60 Hz
• Power consumption: 70W, 2A
• Dimensions: 3.7" x 18.4" x 19"
• Weight: 13 lbs
• General Specs:
• Loading capacity: 8.8m pixels
• Max W/H: 10,240 pixels
• XR functions
• LED image booster 2.0
• Dynamic booster
• Full grayscale calibration
• Low latency (< 1 ms)
• HDR functions
• Warranty: 3 Year
