ProX XTP-E1020-3 Double Circle 10X20 Exhibition Module Stand Truss Package

Description

The ProX Double Circle XTP-E1020-3 Truss makes it easy to hang accessories like lighting, screens, speakers, signage, time clocks, LCD panels, and announcer sound systems. ProX Truss has the most trusted staging support systems in the industry and is built to the highest standards of safety and performance. It's a rugged yet lightweight trussing solution perfect for mobile DJs, bands, outdoor performances, nightclubs, live mobile productions, or permanent installations. Together with ProX, you can make sure the participants have an experience they will remember.

ProX offers a wide array of small to medium temporary booth and trade show solutions to suit all types of indoor and outdoor events. Custom temporary DJ and Production set projects are a specialty of the ProX Engineering Department, which focuses on safety and stability of its designs. Work with ProX's experienced Truss and Show Designers to help you easily build that unique, safe professional looking display you have in mind with ProX Truss. All ProX Truss products are 100% compatible to connect along with many other manufacturers. All ProX Trussing is constructed to the highest safety ratings by certified welders.

Features:

• Manufactured to Exacting Specifications in ProX's own Factory.
• Individual XT-SQ820 Length: 8.2 ft (2.5 Meter) Square Truss Segment.
• Individual XT-SQ820 Weight: 36 Lbs.
• Includes Connecting Hardware Set.
• Material: EN-AWT6 6082 Aluminum.
• TUV Certified Aluminum Welding.

Specifications:

• Dimensions:
  • 6.6m W x 3m L x 4.58m H
  • 21.65W x 9.84L x 15H (ft)
• Exterior Dimensions & Weight:
  • XT-BP12A (4): 1.50"H x 12.00"W x 12.00"L - Weight: 4.00 lbs
  • XT-CSQ656-2X180 (2): 36.00"H x 24.00"W x 72.00"L - Weight: 96.00 lbs
  • XT-JB6W-4W (10): 11.45"H x 11.45"W x 11.45"L - Weight: 17.00 lbs
  • XT-SQ164 (4): 19.68"H x 11.42"W x 11.42"L - Weight: 13.00 lbs
  • XT-SQ328 (2): 39.36"H x 11.42"W x 11.42"L - Weight: 19.00 lbs
  • XT-SQ492 (2): 59.04"H x 12.00"W x 12.00"L - Weight: 25.00 lbs
  • XT-SQ820 (3): 98.40"H x 12.00"W x 12.00"L - Weight: 36.00 lbs
  • XT-SQ984 (5): 118.08"H x 12.00"W x 12.00"L - Weight: 42.00 lbs
• Shipping Dimensions & Weight:
  • Box 1 of 6: XT-BP12A (4 boxes) 2.00"H x 13.00"W x 13.00"L - Shipping Weight: 5.00 lbs
  • Box 2 of 6: XT-CSQ656-2X180 (2 boxes) 36.00"H x 24.00"W x 72.00"L - Shipping Weight: 96.00 lbs
  • Box 3 of 6: XT-JB6W-4W (10 boxes) 12.50"H x 12.50"W x 12.50"L - Shipping Weight: 17.50 lbs
  • Box 4 of 6: XT-SQ164 (4 boxes) 22.00"H x 14.00"W x 14.00"L - Shipping Weight: 15.00 lbs
  • Box 5 of 6: XT-SQ328 (2 boxes) 41.50"H x 12.50"W x 12.50"L - Shipping Weight: 21.00 lbs
  • Box 6 of 6: XT-SQ984 (5 boxes) 14.00"H x 14.00"W x 120.00"L - Shipping Weight: 46.00 lbs

Whta's in the Box?

• (5) ProX XT-SQ984 3m Truss Sections
• (3) ProX XT-SQ820 2.50 m Truss Sections
• (2) ProX XT-SQ492 1.5m Truss Sections
• (2) ProX XT-SQ328 1m Truss Sections
• (4) ProX XT-SQ164 0.5 m Truss Sections
• (2) ProX XT-CSQ656-2x180 2m Circle Trusses
• (10) ProX XT-JB6W-2W Junction Boxes
• (4) ProX XT-BP1212A 1'x1' Al. Base Plates
• (8) ProX XT-CP 103P Junction Box Connectors
