Stanton Studio Kit

Two Stanton C.324 CD Players

• Tabletop CD player with touch sensitive jog wheel for scratching and beat juggling
• CD slot drive mechanism
• MP3 playback with text display and onboard file and folder browsing
• Onboard pattern and real-time sequencer for on-the-fly drum machine style Performances
• 7 high-quality beat synchronized digital effects: Filter, Auto Filter, Echo, Phaser, Flanger, Transform, Pan
• Beat synchronized sampling and looping with four trigger pads and Cue Memory
• Auto and manual BPM control
• Vinyl emulation with adjustable Platter Start/Brake Speed
• Adjustable pitch (+/- 8%, 16%, 25%, 100%) with Pitch Bend
• Key Lock allows a song's tempo to be changed without affecting the original key of the song
• Reliable anti-shock playback with auto cue
• Blue LCD display with visual marker for S/PDIF digital output
• Frequencey Response: 20Hz to 20kHz +/- 1.5 dB
• THD+N with 20kHz low-pass filter: 0.015% at 1kHz
• S/N Ratio with 20kHz low-pass filter and IHF-A Weighted: 85 dB
• Output level: +6 dBV (1 Vrms) +/- 1dB at 1kHz, 0dB
• Channel balance: within 1 dB at 1kHz, 0dB
• De-Emphasis response: +3/-0 dB at 16kHz, -20 dB
• Channel separation with 20kHz low-pass filter and IHF-A Weighted: 90 dB at 1kHz, 0 dB
• Searching time: Test Disc: TCD-792)
• Short Access Time: 2 sec play next track
• Long Access Time: 4 sec track 1 to 20, 20 to 1
• Playability: 0.7mm TDC-725
• Interruption: 0.6mm TDC-725
• Black Dot: 65um TDC-725
• Finger Prints: 140um TDC-712 W/O Track Jump
• Eccentricity: 0.5mm TDC-731R
• Power Supply: AC 120V, 60Hz, 15W
• Dimensions: 318mm(W) x 92mm(H) x358mm(D)
• Weight: 4.4 kgs.

Numark M4 Mixer

• Three-channel tabletop mixer
• Inputs: two phono/line switchable (RCA), four line (RCA), mic (1/4 inch)
• Outputs: Master (RCA), Record (RCA), headphone (1/4 inch stereo)
• Steep three-band EQ/rotary kills on each channel
• Microphone input with EQ
• Six-segment LED display for monitoring signal strength
• Toggle for master and PFL metering
• Replaceable crossfader with reverse and slope controls

Traktor Scratch Duo Software

• For aspiring DJs who want to start spinning their digital tracks on vinyl and CD, Traktor Scratch DUO is the complete solution that provides both the software and hardware to perfectly fuse the worlds of analog and digital DJing. Traktor Scratch DUO comes with the powerful Traktor PRO-based Traktor DUO software, the professional AUDIO 4 DJ interface, ultra-precise control records and CDs plus many more valuable features to get you spinning in no time.
• Control up to 2 decks using turntables, CD decks or MIDI controllers including advanced looping and cue points
• High-end 24-bit/96 kHz low-latency audio interface with Cirrus Logic(R) AD/DA converters; USB 2.0 bus powered
• 4 high-gain outputs, 4 inputs with optional phono-pre amps with high impedance input mode for perfect audio through quality, 8 individual LEDs for full visual control, high power 1/4" headphone jack with independent volume knob
• 2 control vinyl records and 2 CDs with high-resolution 2 kHz signal for ultra-precise track control
• 2 Multicore cables (patent pending) for easy plug and play connectivity
• Stylish interface utilizing the same engine as the industry leading Traktor PRO-designed for high visibility in club environments
• 6 first-class DJ effects (delay, flanger, reverb, filter, beatmasher, gater), groupable into chains of up to three per channel
• Advanced DJ software based on Traktor PRO includes high-end internal mixer, automatic beat-gridding of tracks, advanced beat detection and Sync Lock for perfect mixing
• Realtime track management with incremental search, Crate-Flick browsing, iPod(R) and iTunes(R) compatibility
• Supports multiple USB controllers and assignments and includes ready-to-use mappings for almost all industry-standard controllers

Go Duo

The included Traktor DUO software features two state-of-the-art playback decks, an intuitive graphic interface with a Crate Flick cover art browser. Advanced looping capabilities, with multiple loop and cue points plus up to three chainable tempo sync'd effects per channel let you get deep inside the tracks you spin. Traktor Scratch DUO combines unparalleled creative potential with ease of use and rock-solid dependability.

Fab 4

Traktor Scratch DUO comes with AUDIO 4 DJ, a superior USB bus-powered audio interface built specifically for DJing. This low-latency 24-bit/96 kHz interface uses high-end Cirrus Logic(R) AD/DA converters for pristine audio quality - just like its multi award-winning big brother AUDIO 8 DJ. Four switchable inputs and four hi-gain (9.7 dBu) outputs let you connect to an external mixer and turntables or CD decks in seconds.

Digital Tracks On Wax

Traktor Scratch DUO enables you to seamlessly fuse analog and digital DJing. The 2 kHz control signal of the included vinyl and CDs is twice the resolution of the competitors. This unmatched responsiveness means that everything from slow rubs to quick backspins and even motor-offs responds just like vinyl. Pressed with extreme care onto high-quality 120g discs, it feels like each digital file is cut into the wax.

Easy Setup

Traktor Scratch DUO is designed for easy set up and comes with a dedicated set of high-quality Multicore cables. Within seconds, you can hook up the AUDIO 4 DJ to your turntables / CD players and mixer and you're ready to rock. And with the included Traktor DUO software you can also spin without CD decks and turntables using the internal mixer- perfect for preparing a set or rocking an after party.

Scratch Library

Traktor Scratch DUO comes with a dedicated Scratch Library. The included exclusive audio material offers instant usability and unique features for all turntablists. Over 700 MB of sounds recorded in 24 bit / 96 kHz audio quality are itching to be Scratched and include many lead sounds for solo Scratching as well as sound FX, endless tones, tunes for juggling, loops and more.

Specifications

• Audio Inputs (A/D)
• Channels: 4
• Sample Rate: 44.1, 48, 88.2, 96 kHz
• Bit Resolution: 16, 24-bit
• Converter: Cirrus Logic

Line Inputs

• Input Impedance: 1 MOhm
• Full Scale Level: + 12,5 dBu
• SNR (weighted): 99,7 dBu
• THD+N: 0,019%
• Frequency Response +/-1 dBu: 10 Hz-40 kHz
• Dynamic Range codec: 105 dBu

Phono Inputs

• Input Impedance: 47 KOhm
• Full Scale Level @ 1 kHz: - 21,2 dBu
• (weighted) @ 1 kHz: 87,2 dBu
• THD+N @ 1KHz: 0,09%
• Frequency Response +/-1 dBu: 10 Hz-40 kHz

Audio Outputs (D/A)

• Channels: 4
• Sample Rate: 44.1, 48, 88.2, 96 kHz
• Bit Resolution: 16, 24-bit
• Converter: Cirrus Logic

Line Outputs

• Output Impedance: 100 Ohms
• Maximum Output Level: +9,6 dBu
• SNR (weighted): 100 dBu
• THD+N: 0,006%
• Frequency Response +/- 1 dBu: 10 Hz-40 kHz
• Dynamic Range codec: 105 dBu

Headphone Output

• Load Impedance: 16 Ohms - 600 Ohms
• Maximum Output Level (100 Ohm load): 1,55 V RMS (load 100Ohm), 3,1V RMS (no load)
• (weighted): 93 dBu
• THD+N (100 Ohms): 0,016%
• Frequency Response +/- 1 dBu: 10 Hz-40 kHz

System Requirements

• Windows(R) XP (SP2, 32 Bit)/Vista (SP1, 32 Bit, 64 Bit), Windows 7, Pentium IV or Athlon 1.4 GHz (SSE1), 1 GB RAM
• Mac OS(R) X 10.4, Intel(R) Core(TM) Duo 1.66 GHz, 1 GB RAM

Dimensions

• 4 (101 mm) x 4.8 (121 mm) x 1.7 in.(42 mm)
• Weight: 1.1 lb (511 grams)

Supported Drivers

• ASIO(TM), Core Audio(TM), DirectSound(R), WASAPI(TM)

Power Supply

• Power Supply Via USB 2.0 interface, 5V 500mA bus power. No additional power supply or battery is needed.

Two KRK Rokit 5 RP5G2 Speakers

• The KRK RP5G2 Rokit G2 Powered Studio Monitor takes this KRK design to new heights. All of the great stuff that Rokit's have been known for including front-firing bass port, soft-domed tweeter, glass aramid composite yellow cone are still there, but the G2 Rokit's feature refined voicing and a new curved baffle that looks great, reduces diffraction and provides even better monitoring accuracy.
• Radically curved front plate design virtually eliminates diffraction distortion
• Waveguide design provides amazing detail and imaging
• Front-firing port provides low freq extension without boundary coupling
• New speaker voicing for even more accurate frequency response
• 1" Neodymium soft dome tweeter
• Glass Aramid Composite Cone Woofer
• Frequency Response 53Hz to 20kHz
• Peak SPL : 106dB

ALL CABLES INCLUDED!
