Express 112A DJ System

Overview

Numark MixDeck Express Digital DJ Controller

• Complete system with CD/MP3/USB decks, mixer, computer audio and MIDI interface
• MIDI integration of decks for controlling computer software
• Virtual DJ Audio/Karaoke/Video software included
• Play from CDs, MP3 CDs, USB flash drives, computers, and external inputs
• Three-channel mixer with EQ/rotary kills, replaceable crossfader, and external inputs
• USB computer interface for software control and audio streaming
• Brake, Reverse, and Scratch effects
• Smooth, fast, slot-loading drives with large, touch-sensitive platters
• Control MIDI software, with no timecode needed, via USB
• Automatic BPM analyzer and Tap tempo for manual BPM entry
• ±6, 12, 25, 100% Pitch Ranges
• Seamless looping
• Single-track, continuous, and programmable playback
• Two large, backlit displays for BPM, CD/MP3 text tags, and folder navigation
• Anti-Shock™ buffered skip-protection technology
• Fader Start – crossfader play activation

Two Alto TS112A Powered DJ Speakers

• ACTIVE 800 WATT 2-WAY 12" LOUDSPEAKER
• 800 Watts Class D power
• 12" low-frequency transducer, 1" neodymium driver
• Two Mic/Line combo inputs with independent volume controls
• XLR output to link speakers
• Lightweight, trapezoidal cabinet with handles
• Use as a traditional upright loudspeaker or as floor wedge monitor
• Stand and pole-mountable or flyable
• Clip Limiter with red LED
• Ground Lift switch
• Contour switch for increased EQ control
• Accurate audience coverage, not just on-axis
• Designed and tuned in the USA
• Transducer Low: 12" Woofer, with 2" voice coil
• Transducer High: Neodymium compression driver, 1" exit with 1" voice coil
• Power Amplification: 800 Watts peak (670 W LF + 130 W HF), 400 Watts continuous (335 W LF + 65 W HF)
• Frequency Range (-10 dB): 54 Hz - 20 kHz
• Frequency Response (±3 dB): 65 Hz - 19 kHz
• Maximum SPL @ 1m: 125 dB peak, 122 dB continuous
• -6 dB Nominal Coverage: (80° / 100° H x 60° V)
• Active Crossover: 2.5 kHz
• Connectors: 2 x Mic / Line Female XLR - 1/4" combo inputs, 1 x Loop - Out Male XLR
• Input Control: Line / Mic -8 to +50 dB, Maximum input level +23 dBu, Input Impedance 15 kOhms
• External Controls: Volume, Power switch with LED indicator, Clip/Limit LED, Ground Lift switch
• Protection Features: Over-excursion, Thermal, Driver
• AC Power: 100 VAC, or 110 – 120 VAC, or 220 - 240 VAC (50 / 60 Hz)
• Enclosure: Trapezoidal, with floor monitor capability. Injection molded, polypropylene enclosure, with perforated steel grille
• Mounting: Integrated pole-socket (36 mm dia.) Two handles, 5 M10 threaded sockets: 2 top, 2 bottom, 1 pullback
• Dimensions (WxLxH): 15in x 14.3in x 25.5in
• Weight: 35 lb

Alto TS SUB15 Subwoofer

• ACTIVE 1200 WATT 15" SUBWOOFER
• 1200 Watts Class D power
• Powerful 15" low-frequency, long-excursion driver
• Stereo inputs: Mic/Line left channel, XLR right channel
• Stereo XLR outputs: Left link, Right mono, internal 120Hz crossover on through
• 18 mm birch plywood vented cabinet with metal grille and recessed handles
• Adjustable level and polarity controls
• 35 mm pole socket
• Powered System: Continuous-600 Watts, Peak-1200 Watts
• Frequency Response (-10dB): 42 Hz-12 5Hz under analog processor
• Maximum SPL @ 1m: 123 dB continuous / 126 dB Peak
• Transducer Low: 15" woofer, 3" copper sandwich voice coil, with long excursion
• Active Crossover: Band pass type 12 dB / oct. under analog processor
• Input Connectors: In-Left / Mono (Combo) Right (XLR-F) / Out-Left /Mono-Right (XLR - M) / Link-Left / Mono-Right (XLR-M) Balanced (15 kOhm)
• Input: Level L-R Input Line at 0dBu
• Crossover Frequency: L - R output with high pass filter at 80Hz or flat for L-R satellite
• External Controls: Volume control / Phase switch / HPF - 80 Hz bypass / Power-on with green LED / Clip limiter with red LED / Ground lift
• Power Supply: 120 - 240 Volts in switching power mode
• Enclosure Construction: 18 mm plywood cabinet, glued and reinforced, resistant black paint, metal grille, rubber foot, four optional wheels
• Mounting: One standard metal pole-mount, two metal handle
• Dimensions (WxLxH): 591cm x 451cm x 513cm
• Weight: 68.29 lb
