Yamaha DHR10 700W 10-inch Powered Loudspeaker

Clear voice reproduction and extreme musicality

Despite its compact, portable form factor, the DHR10 packs quite a wallop. This active loudspeaker pumps 700 watts of Class D power through a high-compliance 10-inch low-frequency driver and a 1.4-inch high-frequency compression driver. No matter your application, the DHR10 will exceed all expectations with a full-range 52Hz-20kHz frequency response and a rafter-shaking 128dB of maximum SPL. What's more, its 90-degree by 60-degree coverage angle ensures that every seat experiences consistent - and amazing - sound.

Full and detailed imaging from advanced FIR-X tuning

Many loudspeakers exhibit a loss of clarity and/or volume in frequencies near their crossover points, but the Yamaha DHR10 maintains clear sound thanks to advanced FIR-X crossover tuning. Utilizing ultra-precise 48-bit DSP, FIR-X optimizes frequencies and phase relationships to practically eliminate crossover distortion. The result is a smooth, balanced response around the crossover frequencies and a better-sounding performance overall.

Consistent clarity and balance at any volume

While any loudspeaker's tonal balance can vary depending on its output level, the DHR10 features Yamaha's D-Contour intelligent multiband compressor to maintain its sonic integrity at any volume. D-Contour constantly monitors multiple frequency bands and makes real-time adjustments to keep the balance consistent - it won't mess with your mix; it just ensures your mix stays the same at any volume level. And live sound engineers appreciate the flexibility to choose from two operational modes (FOH/Main or Monitor) to optimize the frequency balance depending on your application.

Yamaha DHR10 Powered Speaker Features:

• Compact loudspeaker fueled by 700W of Class D power
• High-compliance 10-inch low-frequency driver; 1.4-inch high-frequency compression driver
• Full-range 52Hz-20kHz frequency response
• Rafter-shaking 128dB maximum SPL
• 90-degree x 60-degree coverage angle ensures consistent, amazing sound throughout the room
• 48-bit DSP optimizes frequencies and phase relationships to mitigate crossover distortion
• D-Contour intelligent multiband compressor maintains sonic integrity at any volume
• Flexible FOH/Main and Monitor operational modes
• Rugged polyurea-coated compact plywood enclosure
• 35mm socket for effortless placement on a stand or pole

Tech Specs

• Powered: Yes
• Power Configuration: Bi-amped
• LF Driver Size: 10" woofer
• HF Driver Size: 1" Compression Driver
• Total Power: 700W Class D
• Inputs: 2 x XLR-1/4" combo
• Outputs: 1 x XLR
• Frequency Response: 52Hz-20kHz
• Maximum Peak SPL: 128 dB SPL @ 1m
• Horizontal Coverage Angle: 90°
• Vertical Coverage Angle: 60°
• Signal Processing: 48-bit DSP
• Enclosure Material: Plywood with Black Polyurea coating
• Mounting Options: Pole
• Power Source: Standard IEC AC cable
• Height: 19.5"
• Width: 12"
• Depth: 11.75"
• Weight: 33 lbs.
