QSC AcousticDesign AD-P6T 6.5-inch 2-way Pendant Speaker-White

Description

The QSC AcousticDesign AD-P6T is a 120-watt, 2-way pendant loudspeaker that maintains tonal consistency across the company's entire AcousticDesign family of products. This speaker's Directivity Matched Transition (DMT) waveguide ensures smooth, uniform frequency response over the coverage area, plus it includes Intrinsic Correction voicings via QSC's Q-Sys platform and CXD amplifiers. You also get low-saturation, low-loss 70V/100V transformers with 16-ohm bypass. We appreciate how easily the AD-P6T integrates into any environment, thanks to its included quick-link suspension cables, slip-lock fasteners, moisture-resistant sealable input cover, snap-fit magnetic grille, and blemish-free removable logo. No matter where you install it, the AcousticDesign AD-P6T will deliver impressive performance time and time again.

Features

• 120W, 2-way pendant loudspeaker
• Ideal for a wide range of foreground and background sound reinforcement applications
• Maintains tonal consistency across QSC's entire AcousticDesign family of products
• Directivity Matched Transition (DMT) waveguide ensures smooth, uniform frequency response over the coverage area
• Intrinsic Correction voicings via QSC's Q-Sys platform and CXD amplifiers
• Low-saturation, low-loss 70V/100V transformers with 16-ohm bypass
• Included quick-link suspension cables and slip-lock fasteners ensure pain-free installation
• Moisture-resistant sealable input cover, snap-fit magnetic grille, and blemish-free removable logo

Specification

• Powered: No
• Power Configuration: 2-way
• Quantity: Single
• LF Driver Size: 6.5" weather treated paper cone woofer
• HF Driver Size: 0.75" aluminum dome tweeter
• Power Rating: 120W
• 70V/100V Output: 70V/100V: 60W, 30W, 15W, 7.5W (70V only)
• Impedance: 16 ohms
• Inputs: 1 x Euroblock
• Outputs: 1 x Euroblock
• Frequency Range: 56Hz-20kHz
• Maximum Peak SPL: 112dB SPL
• Horizontal Coverage Angle: 135 Degrees
• Vertical Coverage Angle: 135 Degrees
• Enclosure Material: ABS with steel grille
• Application: Indoor
• Mounting Options: Suspended
• Width: 11.3"
• Depth: 12.7"
• Weight: 9 lbs.
