PreSonus Eris Studio 5 (Single) 5.25-inch 2-Way Active Studio Monitors with EBM Waveguide

Set up your studio monitors for your room.

Eris® Studio 5 active monitors are equipped with Acoustic Tuning controls to ensure the flattest response in your mix environment. You get Low Cut, Mid, and High controls, as well as three-way Acoustic Space tuning that makes it easy to compensate for the boundary bass boost that occurs when a speaker is placed too close to a wall.

Honest. Expressive. Powerful.

Like all PreSonus® studio monitors, the Eris® Studio 5 offers consistent, accurate listening. Their stylish design makes them a welcome addition to any mix space and their smooth, incredibly even frequency response ensures that your mixes will sound great everywhere.

Features:

• 5.25-inch woven composite low-frequency driver
• 1-inch, ultra-low mass, silk-dome, high frequency driver
• Crossover Frequency, 3.5 kHz
• 120° x 60° EBM waveguide provides a sweet spot
• Front-firing acoustic port for superior bass-frequency reproduction and optimized, resonance-suppressing internal bracing
• 80W, Class AB dual amplification
• 48 Hz to 20 kHz frequency response
• 102 dB Peak SPL (@ 1 meter)
• Acoustic Tuning Controls:
• Acoustic Space (Flat, -2 dB, -4 dB)
• High Frequency (±6 dB, center 10 kHz, continuously variable)
• Mid Frequency (±6 dB, center 1 kHz, continuously variable)
• Low Cut (Flat, 80 Hz, 100 Hz @ -12 dB / octave)
• Inputs:
• XLR and 1/4-inch TRS balanced rear-panel inputs
• RCA unbalanced rear-panel inputs
• Protection:
• RF interference
• Output-current limiting
• Over-temperature
• Turn-on/off transient
• Subsonic filter
• Power Saver mode (engages after 40 minutes)

Specifications:

• Electronics
  • Voltage : 100-120V
  • Wattage : 80 Watts
• Miscellaneous
  • Connection Type : IEC
• Hardware
  • Cabinet Material : Vinyl-Laminated, Medium-Density Fiberboard
• Monitors
  • Protections
    • RF interference
    • Output-current limiting
    • Over-temperature
    • Turn-on/off transient
    • Subsonic filter
  • Audio Switches : Acoustic Space (Flat, -2 dB, -4 dB)Low Cut (Flat, 80 Hz, 100 Hz @ -12 dB / octave)
  • Audio Controls : VolumeHigh Frequency (±6 dB, center 10 kHz, continuously variable)Mid Frequency (±6 dB, center 1 kHz, continuously variable)
  • Peak SPL : 102 dB (@ 1 meter)
  • Crossover Frequency : 3.5 kHz
  • Monitor Inputs : 1- Balanced XLR, 1- Balanced 1/4" TRS, 1- Unbalanced RCA
  • HF Transducers : 1" Ultra Low Mass, Silk Dome Tweeter
  • LF Transducers : 5.25" Woven Glass Fiber Composite
  • Frequency Response : 48 Hz - 20 kHz
  • Input Impedance : 10 kΩ
  • Coverage Pattern : 120 degree (H) x 60 degree (V)
  • Monitor Amplifier Power : LF Amplifier - 45W, HF Amplifier - 35W
• Input Impedance : 10 kΩ
