Peavey PVX™ 10

The PVX™ 10 is a two-way sound reinforcement system based on a heavy-duty 10" woofer and a RX™ 10N titanium diaphragm dynamic compression driver mounted on a 100° by 60° coverage Quadratic Throat Waveguide™. Its sleek modern appearance coupled with excellent performance offer an outstanding package.

Features PVX™ 10

• Power Handling: 400 Watts program / 800 Watts peak
• Two-way sound reinforcement enclosure
• Crossover network for driver protection and EQ
• High frequency driver protection
• Durable plastic injection-molded trapezoidal enclosure
• Asymmetrical horn aims the sound down 10°, at the audience, not over their heads
• Full-coverage heavy-duty perforated steel grilles, with powder coat finish
• Pole mount molded-In
• Top and bottom flying point inserts
• Patented Quadratic Throat Waveguide™ technology, 100° x 60° coverage
• RX 10N compression driver, with 1" titanium diaphragm
• 10" heavy-duty woofer with 2 3/8" voice coil & 50 oz. magnet
• Extra angled section on right side allows floor monitor use

Specification:

• Speaker Configuration : Full Range 2-way
• Speaker Type : Non-Powered
• Power RMS : 200 W
• Power Program : 400 W
• Power Peak : 800 W
• Nominal Impedance : 8 O
• Sensitivity (1W/1m) : 93 dB
• Maximum SPL : 122 dB
• Speaker Frequency Response : 74 Hz - 18 kHz (±3 dB)
• Coverage (H x V) : 100° x 60°
• HF Driver : RX™ 10N - 1" Titanium Diaphragma Compression Driver
• LF Driver : 10", VC 2 3/8" Woofer
• Input Connectors : 1 x 4-pin Twist-Lock & 1 x 1/4" Jack
• Suspension Points : 4 x M10 & 2 x VersaMount 70+
• Pole Mount : Yes
• Enclosure Material : ABS
• Color : Black
• Net Weight : 25.0 lbs (11.30 kg)
• Product Height : 20.00" (508 mm)
• Product Width : 12.69" (322 mm)
• Product Depth : 11.06" (281 mm)
