KRK V8 S4

Overview

KRK Systems V Series 8 nearfield studio monitors are specifically designed for audio production applications where accurate reproduction is critical. KRK worked with hundreds of pro engineers/producers/mixers to develop these groundbreaking monitors. Recording and broadcast studios as well as sound design and audio production houses will benefit from adding the V Series 8 as the go to monitor of choice.

V-Series 8 includes 49 user selectable EQ settings to ensure proper setup for room acoustics and placement anomalies as well as taste and individual preference. The KRK design team has painstakingly modeled and analyzed hundreds of monitor placement and room acoustic situations to ensure that KRK delivers the most useful tools with minimal adjustments.

KRK V8 S4 Features

• KRK custom designed Kevlar tweeter
• KRK custom designed Woven Kevlar woofer
• Optimized front ported bass reflex enclosure design
• Bi-amped Class-D amplification
• Acoustic and desk loading condition correction Low Frequency EQ's
• Mid and High Frequency EQ's
• Precise input level attenuation switch
• Standby, ground lift, input sensitivity, and logo LED selectors
• Optional protective grille included for mobile broadcast applications
• Friction lock, Neutrik combo (XLR and TRS) connector
• Robust EVA foam pad for non-skid and acoustic isolation
• Universal threaded mounting bracket points

KRK V8 S4 Technical Specifications

• Configuration:2-Way
• System type:Active Studio Monitor
• Low-Frequency:Woofer, 8" cast aluminum frame, Kevlar cone, ferrite magnet
• High-Frequency:Tweeter, 1", Kevlar dome, ferrite magnet
• Frequency Response:35Hz - 19kHz
• Frequency Range:29Hz - 24kHz
• Max Peak SPL:118 dBSPL
• Power Output:LF (200 Watts), HF (30 Watts), Total (230 Watts)
• High Control:H1 (High Shelf -2dB 10kHz, H2 (High Shelf -1dB 10kHz / High Mid Peq -1dB 3.5kHz), H3 (High Mid Peq -1dB 3.5kHz), H4 (Flat), H5 (High Mid Peq +1dB 3.5kHz), H6 (High Shelf +1dB 10kHz / High Mid Peq +1dB 3.5kHz, H7 (High Shelf +2dB 10kHz)
• Low Control:L1 (Low Shelf -3dB 75Hz), L2 (Low Shelf -1.5dB 75Hz), L3 (Low Shelf -2dB 75Hz / Low Mid Peq -2dB 200Hz), L4 (Flat), L5 (Low Mid Peq -2dB 200Hz), L6 (Low Shelf +1.5dB 75Hz), L7 (Low Shelf +3dB 75Hz)
• Enclosure Construction:MDF / Aluminum
• Grille:Included
• Dimensions (H x W x D): 17.13" (435mm) x 11.18" (284mm) x 13.66" (347mm)
• Weight:31.75 Lbs. (14.4 Kg.)

KRK V8 S4 Support / Documentation

• Cutsheet
• Quick Start Guide
• User Manual
