Electro Voice EVID 6.2 White Pair

Description

The EVID 6.2 is comprised of dual, six-inch, low-frequency drivers and a one-inch, Ti/waveguide. The 6.2 is perfect for applications that require exemplary audio and the capability to fill large spaces with sound. The flexible Strong-Arm-Mount™ (SAM™) system provides versatility to accommodate any installation challenge. EV's unique, six-inch, dual woofer design delivers crisp and clean program for the best listening experience regardless of the location. This system is great for larger areas that demand higher SPL levels. The EVID 6.2 delivers the outstanding, full-bass output required for shopping malls, stadiums, and airports.

The EVID 6.2 is an extended-range loudspeaker ideal for indoor and outdoor applications requiring high-quality sound. Its extended range and smooth bass provide ample SPL levels in larger environments such as shopping malls, sports bars, health clubs, and so on.
The 6.2's three-dimensional elliptic baffle symmetrically locates the 1" Ti direct radiator high-frequency element with a Coherent Coverage Waveguide in front of and between the 6" low-frequency drivers. The careful shaping, location, and 10° splaying of the LF units provide coverage control by the resulting line array. Lobing is controlled by physically "shadowing" the LF transducers from each other over the bandwidth where they would normally exhibit interference.
EVID's mounting system provides greater range of aiming angles in both horizontal and vertical planes than other types. The curved grille features designed-in weather resistance and a hidden leash for safety.
All models are available in black or white, and can easily be painted to match the d'cor. Transformer versions are also available for constant voltage systems.

• Horizontal Coverage: 100°

• Max SPL: 118 dB

• "T" version wattage taps: 70V/100V: 15W, 30W, 60W

• Dimensions (H x W x D): 16.5" x 9" x 11.75"

• Enclosure Material: ABS (paintable)

• Frequency Response: (-10 dB): 62 Hz-20 kHz

• HF Transducer: 1" (25 mm)

• Horizontal Coverage: 100°

• Impedance: 8 ohms

• Included Accessories: SAM, hex key

• LF Transducer: 2 x 6" (150 mm)

• Max SPL: 118 dB

• Net Weight (each): 12 lbs

• Power Handling: 300 watts

• Protection: Full System

• Sensitivity: 94 dB, 1 W/1 m

• Shipping Weight (pair): 27 lbs

• Suspension: Multi-Axis

• Swing & Rotation: 100° x 90°

• Terminals: Spring

• Vertical Coverage: 80°

• Net Weight (each): 12 lbs

• Sensitivity: 94 dB, 1 W/1 m

• Vertical Coverage: 80°

• Impedance: 8 ohms

• Frequency Response1 (-10 dB): 62 Hz-20 kHz

• "T" version wattage taps: 70V/100V: 15W, 30W, 60W

• Included Accessories: SAM, hex key

• Enclosure Material: ABS (paintable)

• Terminals: Spring

• HF Transducer: 1" (25 mm)

• LF Transducer: 2 x 6" (150 mm)

• Protection: Full System

• Swing & Rotation: 100° x 90°

• Power Handling: 300 watts

• Suspension: Multi-Axis

• Shipping Weight (pair): 27 lbs

• Dimensions (H x W x D): 16.5" x 9" x 11.75"
