Electro Voice Evolve 30M

Ultra-portable, collapsible design saves you time and effort

Lugging a heavy PA into the venue is a lot of work. The Electro-Voice Evolve 30M seeks to change that. Weighing almost 15 lbs. less than its predecessor, the Evolve 50, this PA tips the scales at just 44 lbs. To make transportation easy, the Evolve 30M ships to your door with an included backpack for the column array and the aluminum speaker pole. Setup is simple, the 2-section aluminum pole mounts into the subwoofer and transmits audio to the column array via internal integrated speaker wires. The intuitive design helps you get set up for your gig in no time at all. Just plug it all in and play!

The fully configurable digital mixer is ready for anything

The Evolve 30M has a fully configurable 8-channel digital mixer that you can control from your smartphone via the QuickSmart mobile app. You get four presets to cover some of the situations you may encounter. It includes a 3-band EQ, onboard compressor, dual FX sends and independent channel gain controls. In the app, you can add any one of the 30 professional-quality effects to your mix, including reverb, delay, chorus, flanger, and echo!

Neodymium drivers deliver top-notch sound and expansive coverage

The Evolve 30 is a sonic powerhouse. The column array is loaded with six 2.8" neodymium high-frequency drivers and a proprietary waveguide that provides an impressive 120° of horizontal coverage and 40° of vertical coverage. The excellent sound quality and dispersion of the column array is paired with the raw power of the ported 10" subwoofer to produce up to 123dB SPL with a frequency response as low as 45 Hz. No matter where you're playing, you can rest assured that every inch of the venue receives the best sound possible.

Electro-Voice EVOLVE 30M Features:

• 1,000-watt system packs a big punch
• Collapsible design allows for compact storage and easy transport
• Composite waveguides provide spacious coverage for the entire venue
• Six column-arrayed HF drivers and 10" LF driver deliver impressive power
• 4 factory presets (Music, Live, Speech, and Club) help you set up for common situations
• 3-band EQ makes sound shaping simple and easy
• Built-in Bluetooth connectivity allows you stream music seamlessly for intermission or backing tracks
• QuickSmart mobile app provides powerful DSP and a variety of professional effects
• Phantom power enables use with condenser microphones

Tech Specs

• Powered: Yes
• Power Configuration: Bi-amped
• Channels: 8-channel mixer
• LF Driver Size: 10" woofer
• HF Driver Size: 6 x 2.8"
• LF Driver Power Amp: 500W
• HF Driver Power Amp: 500W
• Total Power: 1000W
• Inputs: 4 x XLR-1/4" combo, 2 x XLR-1/4" combo (stereo), 1 x 1/4" TRS (Hi-Z), Dual RCA Stereo, 1 x 1/8" (aux)
• Outputs: 2 x XLR (mix/aux)
• Other I/O: 1 x 1/4" (footswitch)
• Wireless: Bluetooth
• Frequency Range: 45Hz to 20KHz (-10 dB)
• Frequency Response: 51Hz-20kHz
• Crossover Frequency: 200 Hz
• Maximum Peak SPL: 123 dB SPL @ 1m
• Horizontal Coverage Angle: 120°
• Vertical Coverage Angle: 40°
• Signal Processing: DSP Presets, 7-band Graphic EQ
• Enclosure Material: 15mm Plywood, Composite column, Aluminum pole
• Mounting Options: Floor
• Power Source: Standard IEC AC power cable
• Height: 17.6" (sub), 24.4" (column)
• Width: 13" (sub), 3.7" (column)
• Depth: 17" (sub), 6.2" (column)
• Weight: 44 lbs.
• Manufacturer Part Number: F.01U.366.319
