Key Features

• 24-bit/192kHz resolution for professional recording and monitoring
• Hi-Speed USB circuitry for fastest connection, with class-leading round-trip latency of 2.59ms*
• Transparent Crystal™ preamps and ultra-pristine A/D converters for unsurpassed audio recording quality
• VU LED meters for dialing in the perfect level
• (4) XLR+¼" TRS combo inputs, (2) ¼" instrument inputs and (2) ¼" line inputs
• MIDI input/output for connecting virtually any external MIDI gear
• Stereo ¼" with direct mono/stereo switch; (2) ¼" assignable auxiliary outs
• (2) ¼" headphone outputs with independent source and level controls
• Rugged metal chassis; large central control for easy volume adjustment
• USB/Direct knob for balancing between the input signal and the computer signal
• *Round trip latency is dependent on buffer settings, and computer hardware

Specifications

Minimum System Requirements

• Standard USB 2.0 or USB-C Port
• Windows: 7 (32 or 64 bit)
• OSX: 10.8

Mic Inputs 1-4 (balanced XLR)

• FREQUENCY RESPONSE 20 Hz - 20 kHz (+/-0.2 dB)
• DYNAMIC RANGE 113 dB (A-weighted)
• THD+N 0.003%
• PREAMP EIN -137 dBu (40 Ω source, A-weighted) -129 dBu (150 Ω source, unweighted)
• MAX INPUT LEVEL +14 dBu
• GAIN RANGE 62 dB

Line Inputs 1-4 (balanced 1/4" [6.35 mm] TRS)

• FREQUENCY RESPONSE 20 Hz - 20 kHz (+/-0.1 dB)
• DYNAMIC RANGE 113 dB (A-weighted)
• THD+N 0.001% (1 kHz, +4 dBu, -1 dBFS)
• MAX INPUT LEVEL +30 dBu
• GAIN RANGE 61 dB

Inst Inputs 5-6 (unbalanced 1/4" [6.35 mm] TS)

• FREQUENCY RESPONSE 20 Hz - 20 kHz (+/-0.1 dB)
• DYNAMIC RANGE 110 dB (A-weighted)
• THD+N 0.001% (1 kHz, +4 dBu, -1 dBFS)
• MAX INPUT LEVEL +16 dBu
• INPUT IMPEDANCE ~1 MΩ
• GAIN RANGE 59 dB

Fixed Line Inputs 7-8 (balanced 1/4" TRS)

• DYNAMIC RANGE 113 dB (A-weighted)
• THD+N 0.001% (1 kHz, +4 dBu, -1 dBFS)
• FREQUENCY RESPONSE 20 Hz - 20 kHz (+/-0.1 dB)
• MAX INPUT LEVEL +17 dBu

Line Outputs 1-2 (balanced 1/4" TRS)

• DYNAMIC RANGE 112 dB (A-weighted)
• THD+N 0.002% (1 kHz, -1 dBFS)
• FREQUENCY RESPONSE 20 Hz - 20 kHz (+/-0.2 dB)
• MAXIMUM OUTPUT LEVEL +17 dBu

Fixed Line Outputs 3-4 (balanced 1/4" TRS)

• DYNAMIC RANGE 113 dB (A-weighted)
• THD+N 0.002% (1 kHz, -1 dBFS)
• FREQUENCY RESPONSE 20 Hz - 20 kHz (+/-0.2 dB)
• MAXIMUM OUTPUT LEVEL +17 dBu

Headphone Outputs (stereo 1/4")

• DYNAMIC RANGE 111 dB (A-weighted, 32 Ω load)
• THD+N 0.002% (1 kHz, -1 dBFS, 10 mW/channel into 32 Ω load)
• FREQUENCY RESPONSE 20 Hz - 20 kHz (+/-0.2 dB)
• MAXIMUM POWER DELIVERED 160mW (< 1% THD, 32 Ω load)
• OUTPUT LEVEL +15 dBu (unloaded)
• RANGE 32 Ω - 600 Ω

General

• OTHER CONNECTORS (1) 1/8" (3.5 mm) MIDI input
  (1) 1/8" (3.5 mm) MIDI output
  (1) USB Type-C port
  (1) Power adapter input
• ADAPTER 12 VAC, 2 A, center-positive (included)
• DIMENSIONS (WIDTH X DEPTH X HEIGHT) 10.2" x 7.3" x 3.6" (25.9 x 18.6 x 9.1 cm)
• WEIGHT 3.9 lbs. 1.8 kg

What's In The Box

• AIR 192|14
• USB-C-to-USB-C Cable
• USB-C-to-USB-A Cable
• (2) 1/8" (3.5 mm) to MIDI Adapters
• Software Download Cards
• User Guide
• Safety and Warranty Manual
