AudioBox iOne

Description

The interface for guitarists and songwriters on the go.

Inspiration is everywhere for singer/songwriters, so bring your studio with you and record wherever you go. The PreSonus AudioBox® iOne lets you capture your voice and instrument on your Mac, Windows PC, and iPad. Simply plug in your guitar and microphone, and you're ready to create! USB bus-powered and bundled with powerful, easy-to-use recording software, the AudioBox iOne makes it easy to capture ideas and create professional-quality recordings.

Mobile recording made easy.

The AudioBox iOne and its software library make recording your compositions and tracks easy! Record in stereo on your iPad with free Capture™ Duo or record up to 32 tracks with affordable Capture for iPad. Then wirelessly beam your iPad tracks to our award-winning Studio One® recording and production software for Mac or Windows for editing and mixing. Or do the whole project on your laptop with Studio One. Either way, the AudioBox iOne and its software library provide all the tools needed to record on the road and in the studio.

Loud and clear

To record great-sounding music, you need outstanding preamps and digital converters. And to hear what you're doing, you need a headphone amp that keeps up with the rest of the design. The AudioBox iOne delivers it all! We're famous for our award-winning microphone preamplifiers, and we've equipped the AudioBox iOne with a new, sweet-sounding mic preamp that will capture your voice in all its glory. Clean, clear, 24-bit, 96 kHz digital converters and an ultra-loud, crystal-clear headphone output ensures you hear every detail.

Built to travel.

AudioBox iOne is a mobile interface in the best sense of the term. It can sit on a tabletop or fit in the pocket of a backpack or laptop bag and works with standard iOS power accessories. Its metal chassis is built like a small tank - yet it weighs just 1.35 pounds (0.63 kg). Wherever your travels take you, whenever your creative muse calls, your AudioBox iOne interface will be ready to help you compose and record your masterpiece. Check it out at your favorite PreSonus® dealer.

Features

Core Technology

• Bus-powered USB 2.0/iPad audio interface
• 24-bit resolution; 44.1, 48, 88.2, and 96 kHz sampling rate

Inputs and Outputs

• 1 microphone input with low-noise, high-headroom, Class A mic preamplifier and +48V phantom power
• 1 instrument input
• 2 balanced 1/4" TRS main line-level outputs
• Stereo headphone output with independent level control

Controls

• Zero-latency monitoring via internal analog mixer (fixed 50/50 mix via Direct button)
• Large main volume knob
• Signal present and clipping LEDs

Integrated Software

• Studio One® Artist DAW software (Mac/Windows) and 6+ GB of third-party resources
• Transfer files wirelessly from Capture for iPad to Studio One
• Compatible with almost all recording software for Mac®, Windows®, and iPad®
• Nimbit Free account to distribute and sell your music

Construction and Security

• Kensington lock hole
• Metal chassis

Computer system requirements:

Below are the minimum computer-system requirements for the AudioBox iOne and AudioBox iTwo:

Windows

• Windows® 7 x64/x86 SP1, Windows 8/8.1 x64/x86 or Windows 10 x64/x86
• Intel Core Duo processor (Intel Core i3 or better recommended)
• 4 GB RAM (8 GB or more recommended)

Mac

• Mac® OS X 10.8 or later
• Intel® Core™ Duo processor (Intel Core i3 or better recommended)
• 4 GB RAM (8 GB or more recommended)

Windows and Mac Systems

• USB 2.0 Port
• Internet connection for registration and download of included software
• Internal or external 7200 RPM storage drive highly recommended
• Monitor with at least 1280x800 resolution

Apple iPad

• iPad Pro, iPad Air, iPad mini with Retina display, iPad (4th generation), iPad mini, iPad (3rd generation), iPad 2
• iOS 7.0.1 or higher

The minimum system requirements may differ for DAWs other than Studio One. Please check the requirements for your DAW of choice with its manufacturer.

Note that the speed of your processor, amount of RAM and size and speed of your hard drive will greatly affect the overall performance of your recording system. Also, a more powerful system (faster processor with more RAM) will allow for lower latency (signal delay) than you might experience while monitoring audio or MIDI signals. Monitor resolution for both PC and Macintosh should be no lower than 1024x768 pixels.

Technical Specifications:

Microphone Preamp

• Type : XLR female, balanced
• Frequency Response (±3.0 dB) : 10 Hz to 40 kHz
• Input Impedance (Balanced) : 1,200O
• THD+N (unwtd, 1 kHz @ +4 dBu Output, Unity Gain) : < 0.008%
• S/N Ratio (Unity Gain, Ref. = +4 dBu, 20 Hz to 22 kHz) : > 95 dB
• Common Mode Rejection Ratio (1 kHz, 52 dB Gain) : > 65 dB
• Gain Control Range (± 1 dB) : 0 dB to 52 dB
• Max Input Level (Unity Gain, 1 kHz @ 0.5% THD+N) : +10 dBu
• Phantom Power (±2 VDC) : +48 VDC

Line Input

• Type : Nill
• Input Impedance : Nill

Instrument Input

• Type : 1/4" TS female, unbalanced
• Input Impedance : 1 MO

Line Outputs

• Type : 1/4" TRS female, balanced
• Output Impedance : 51O

Headphone Output

• Type : 1/4" TRS active stereo
• Maximum Output :60 mW/ch. @ 60O Load
• Frequency Response (±1.0 dB) : 20 Hz - 30 kHz
• Output Impedance : 10O

MIDI I/O

• Type : Nill

Digital Audio

• ADC Dynamic Range (A-wtd, 48 kHz Sample Rate) :105 dB
• DAC Dynamic Range (A-wtd, 48 kHz Sample Rate) : 105 dB
• Bit Depth : 24
• Reference Level for 0 dBFS +10 dBu
• Internal Sample Frequency Selections (kHz) : 44.1, 48, 88.2, 96
• Power USB bus-powered

Physical

• Height : 1.71" (43.5 mm)
• Depth : 5.31" (135 mm)
• Width : 5.91" (150 mm)
• Weight :1.35 lbs (0.62 kg)
