Tech 215 Pack

Overview

• Two Pro Speakers
  • 15" 8 way Cabinent Speaker w/ Steel Grill
  • 1500 watts peak power
  • Frequency Response: 45Hz-20kHz
  • 50 oz. magnet
  • Single pole mount, stackable, 2 Integral carry handles
  • 1500 watts peak power
  • Inputs: 1/4" (6.35mm), bare wire terminal
  • Trapezoidal cabinet, perforated steel grill
  • Woofer: Two 2.5" voice coil, 50 oz. magnet
  • Mid: 5" x 15" horn, compression driver 1.5" voice coil, 25 oz. magnet
  • Tweeter: 5 piezo
  • Frequency Response: 45Hz-20kHz
  • Sensitivity: 99 Á±2dB (1W@1M)
  • Impedance: 8 ohms
  • Dimensions: 20.5"w x 47.5"h x 16.5"d (521 x 1207 x 420mm)
  • Weight: 85 lbs (39 kg)
• One Gemini XGA3000 Amplifier
  • 3000 Watt IPP* High Power output to drive professional loudspeakers without clipping
  • Front-to-rear airflow and cooling fan for thermal stability and reliability
  • XLR and ¼" (6.5mm Jack) balanced and RCA unbalanced inputs
  • Limiter circuit switch for amp output protection
  • Stereo, Parallel Mono and Mono Bridge
  • Variable speed fan for low noise
  • Comprehensive front panel indicators including signal, clip, protect
  • 3 Speakon outputs for Channels A/B/Bridge
  • 5-way binding banana plug channel outputs
  • Bridge control switch
  • DC output protection and Short circuit protection
  • Frequency response 10Hz – 50kHz at 1.5 dB
  • Ground lift switch
  • Total Harmonic Distortion: Less than 0.1%
  • Input sensitivity & Impedance: 0.77v
  • Signal to Noise (20 Hz - 20 kHz) > 90dB
• All Connecting Cables
