JRX4000 Bass Pack

Overview

• One Crown XTi4000 Amplifier
  • 650W - 8 ohm Stereo (per channel)
  • 1,200W - 4 ohm Stereo (per channel)
  • 1,600W - 2 ohm Stereo (per channel)
  • 2,400W - 8 ohm Bridge-Mono
  • 3,200W - 4 ohm Bridge-Mono
  • Integrated proprietary DSP with LCD front panel display
  • Accurate, uncolored sound with very low distortion for the best in music and voice reproduction
  • Advanced protection circuitry guards against: shorted outputs, open circuits, DC, mismatched loads, general overheating, high-frequency overloads and internal faults
  • Extremely versatile, handling a wide range of speaker impedances and outputs
  • Switch-mode universal power supply
  • Speaker presets for crossover frequencies, EQ, limiting, and delay
  • All products fill 2U rack spaces and weigh under 17 pounds; weight sets a new standard in lightweight amps (20% less)
  • Speakon® and binding post outputs, XLR inputs and loop-thrus
  • Comprehensive LED status per channel
  • Three-Year, No-Fault, Fully Transferable Warranty completely protects your investment and guarantees its specifications
• Two JBL JRX125 Speakers
  • System Type: Dual 15" 2-way, sound reinforcement speaker
  • Frequency Range (-10 dB):2 35 Hz - 16 kHz
  • Frequency Response (±3 dB):2 45 Hz - 12 kHz
  • Sensitivity (1w/1m): 100 dB SPL
  • Nominal Impedance: 4
  • Power Capacity:1 500 watts
  • Peak Power Capacity:1 2000 watts
  • Maximum SPL: 133 dB
  • Nominal Dispersion: 90° x 50°
  • Crossover Frequency: 2 kHz
  • Dimensions (H x W x D):3 1092 mm x 464 mm x 432 mm (43 in x 18.3 in x 17 in)
  • High Frequency Driver: JBL 2412, 1" exit compression driver mounted on Progressive
  • Transition™ Waveguide
  • Low Frequency Driver: JBL M115-8A x 2
    Input Connectors: Neutrik® Speakon® NL-4 (x1); ¼" TS phone jack (x1); parallel.
  • Enclosure Construction: 19 mm (¾ in) MDF (Medium Density Fiberboard); with glued and mechanically fastened joint detail; covered in black carpet.
  • Grille: 18-gauge, powder-coated steel.
• Two JBL JRX-118S Subwoofers
  • Frequency Range (-10 dB): 38 Hz - 300 Hz
  • Frequency Response (±3 dB): 55 Hz - 300 Hz
  • Sensitivity : 96 dB SPL
  • Nominal Impedence: 4 ohms
  • Power Capacity: 350 watts
  • Peak Power Capacity: 1400 watts
  • Recommended Amplifier Power: 350 watts to 700 watts into 4 ohms
  • Recommended Crossover Settings: 30 Hz HPF, 24 dB / octave; 80 - 100 Hz LPF, 24 dB / octave
  • Maximum SPL: 127 dB
  • Low Frequency Driver: JBL 2043-G
  • Input Connectors: Neutrik® Speakon® NL-4 (x2); ¼" TS phone jack (x1); parallel
• ALL CABLES INCLUDED!!
