EVCV Pack 1

Overview

• Two EV TX1122 Speakers
  • Freq. response (-3 dB): 60Hz - 20kHz
  • Freq. range (-10 dB): 45Hz - 20kHz
  • Rec. Hi-pass frequency: 45Hz
  • Axial sensitivity: 97dB (1W/1m)
  • Max. calculated SPL: 130dB
  • Horizontal coverage: 90 degree
  • Vertical coverage: 50 degree
  • Power handling: 500W continuous 2000W peak
  • LF transducer: SMX2120 12" (305mm) driver
  • HF transducer: DH3 1.25" (32mm) diaphragm compression driver
  • Crossover frequency: 1750Hz
  • Nominal impedance: 8 Ohms
  • Minimum impedance: 5.4 Ohms
  • Connectors: (2) Neutrik Speakon NL4's
  • Enclosure material: plywood and MDF with EVCoat
  • Grille: 16 GA steel black powdercoat with rotatable logo
  • Suspension: (6) 3/8" threaded points - (2) on each side and (2) on the rear of enclosure
  • Dimensions (H x W x D): 24.3" x 15.0" x 15.0" (616mm x 382mm x 380mm)
  • Net weight: 44.5lbs (20.2 kg)
  • Shipping weight: 50.0lbs (22.7 kg)
• Two Cerwin Vega JE36C Subwoofers
  • The new model JE -36B is one of three, new Cerwin-Vega 18" folded horn bass cabinets. It succeeds the LR-36B and features several unique design improvements over the previous model, including a new enclosure design to optimize the horn characteristics; a newly designed 18" woofer with new voice coil technology for sustained power handling and performance and a universal pole mount, which makes the JE-36B an ideal companion for the V-152MKII full range. The JE-36B is an affordable bass cabinet perfectly suited for live sound, Mobile DJ and club applications..
  • Cerwin-Vega's dedication to product excellence routinely includes refinements in design, materials, and workmanship. This ongoing process may result in products which differ from those represented in our descriptive literature due to improvements in design, performance, or both.
  • 18" PORTABLE EARTHQUAKE FOLDED HORN

  • PERFECT FOR PA/PLAYBACK/DISCO

  • 106 dB SENSITIVITY @ 1 WATT/1 METER

  • USE WITH ANY CV'S FULL RANGE SYSTEMS TO OPTIMIZE EXTENDED BASS RESPONSE
  • UNIVERSAL POLE MOUNT
  • Frequency Response: 35 Hz - 300 Hz
  • Program Power Handling: 500 watts

  • Nominal Impedance: 8 Ohms

  • Sensitivity (1w/1m): 106 dB

  • Connections: 1/4"Phone, Neutrik Speakon™

  • 18" Woofer with 3" Voice Coil

  • Durable Multi-Ply Construction

  • High Quality Carpet for Durability
  • Dimensions (HxWxD): 36 " x 24 " x 24 "
  • Weight: 142 lbs.
• Crown XTi-4000 Amplifier
  • Integrated proprietary DSP speaker presets

  • Backlit LCD front panel display

  • Switch-mode universal power supply

  • Proportional-speed fan-assisted cooling

  • XLR inputs, Speakon and binding-post outputs

  • Advanced protection circuitry

  • Comprehensive LED status per channel

  • Three-year, no-fault, fully transferable warranty

  • 2 ohm stereo (per channel) 1600 watts

  • 4 ohm stereo (per channel) 1200 watts

  • 8 ohm stereo (per channel) 650 watts

  • 4 ohm Bridge-Mono 3200W

  • 8 ohm Bridge-Mono 2400W
• Two Speaker Poles
• All Connecting Cables
