Chauvet DJ Intimidator Trio with 2.0 Light Tower

Overview

Trusst Glo Totem 2.0 Truss Lighting Tower with Scrim Cover

Glo Totem 2.0 is an all-in-one kit for the mobile entertainer. The 2 m tall system includes 4 tubes, top and bottom plates, fire retardant scrim, carry bag for tubes, and all connecting hardware. Made of lightweight aluminum for easy transportation, setup, and breakdown, it assembles with the same conical connection system as other Trusst products.

Stress free assembly with no screws or tools to lose, additional mounting holes for lighting fixtures, and convenient integrated carrying handles in the bases make this a perfect addition to your rig.

Glo Totem 2.0 Features:

• All-in-one Glo Totem kit for the mobile entertainer.
• Made of lightweight aluminum for easy transportation, setup, and breakdown.
• Assembles with the same conical connection system as other Trusst products.
• No screws or hex keys to lose for stress-free assembly.
• Additional bolt holes on top plate for secure attachment of lighting fixtures.
• Built-in carrying handles in the bases make transportation a breeze.
• Scrim is manufactured with certified fire retardant material.
• Includes 4 tubes, top and bottom plates, scrim, carry bag for tubes, and all connecting hardware.

Chauvet DJ Intimidator Trio Moving Head

The Intimidator Trio is an innovative, LED-powered moving head with beam, wash and effect features. It allows you to seamlessly change from a narrow beam to a wide wash with the motorized zoom. Its continuously rotating honeycomb delivers the excitement of an effect light and you can generate complex looks easily with built-in, eye-catching auto programs with zone control. The Intimidator Trio features built-in Totem mode that allows the beams to remain focused on the dance floor and coordinated master/slave programs for up to 4 fixtures gives an advanced look with no programming. You can set, save, and recall 1 scene directly from the full-color LCD display and convenient, wireless non-DMX control is at your fingertips using the optional IRC-6 remote. Save time running cables by power linking multiple units.

Intimidator Trio Features:

• Innovative, LED-powered moving head with beam, wash and effect features.
• Seamlessly change from a narrow beam to a wide wash with the motorized zoom.
• Continuously rotating honeycomb delivers the excitement of an effect light.
• Generate complex looks easily with built-in, eye-catching auto programs with zone control.
• Built-in Totem mode allows the beams to remain focused on the dance floor.
• Coordinated master/slave programs for up to 4 fixtures gives an advanced look with no programming.
• Set, save, and recall 1 scene directly from the full-color LCD display.
• Convenient, wireless non-DMX control using the optional IRC-6 remote.
• Save time running cables by power linking multiple units.

Trusst Glo Totem 2.0 Specifications

• Length: 6.56 ft (2.0 m)
• Outer diameter tube: 2 in (50 mm)
• Size (Top Plate): 12 x 12 in (300 x 300 mm)
• Size (Base Plate): 24 x 24 in (300 x 300 mm)
• Base plate thickness: 0.23 in (6 mm)
• Tube wall thickness: 0.08 in (2 mm)
• Weight: 39.4 lb (17.8 kg)

Chauvet DJ Intimidator Trio Specifications

• DMX Channels: 15 or 30
• DMX Connectors: 3-pin XLR
• Pan and Tilt: 540°/270°
• Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 270° tilt
• Light Source: 6 LEDs (quad-color RGBW) 21 W (6.3 A), 50,000 hours life expectancy
• Strobe Rate: 0 to 20 Hz
• PWM Frequency: 1,200 Hz {web only - not for print}
• Zoom Angle : 7° to 53°
• Illuminance (7°): 16,000 lux @ 2m
• Illuminance (53°) : 1,350 lux @ 2 m
• Power Linking: 8 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 232 W, 1 A @ 230 V, 50 Hz
• Weight: 9.2 kg
• Size: 278 x 278 x 386 mm
• Optional Controllers: IRC-6
• Approvals: CE

This Package Includes:

(2) Trusst Glo Totem 2.0 Truss Lighting Towers with Scrim Cover
(2) Chauvet DJ Intimidator Trio Moving Heads

Each Trusst Glo Totem 2.0 Box Includes:

(1) Trusst Glo Totem 2.0

The Totem is comprised of:
(4) Tube Segments
(1) Top Plate
(1) Tower Scrim Cover
(1) Free Carry Bag - For tubes and all connecting hardware
(1) Bottom / Base Plate

Each Intimidator Trio Box Includes:

(1) Chauvet DJ Intimidator Trio
(1) Hanging bracket with mounting hardware
(1) Power cord
(1) Warranty card
(1) Quick reference guide
