Pioneer VSW-1

Description

The VSW-1 is simple in its design and extremely easy to use, ensuring that DVJs are able to mix audio/video content from separate sources without relying upon multiple independent devices or needing another artist in the DVJ booth.

This Video Switcher gives performers more freedom in the mix because they can automatically switch video sources (by pressing the red "Auto" button) when using the familiar Fader Start capability found in all of Pioneer's Pro DJ mixers.

The VSW-1 video switcher gives top DVJs the flexibility they need to take full advantage of Pioneer's revolutionary PIONEER DVJ-X1

When Pioneer Pro DJ announced the PIONEER DVJ-X1, the world's first digital video turntable, video source switching required multiple independent devices or more than one VJ to operate the system. Today Pioneer announces the release of the first video switcher specifically designed with DJs and VJs in mind.

Incorporating the already familiar faderstart capability of Pioneer Pro DJ mixers and players, the VSW-1 gives the DJ more freedom and flexibility in the mix.

At first glance it is apparent how simple the VSW-1 really is. The face of the unit has a red "Auto" button and 2 large illuminated buttons, styled after the Play / Cue buttons of the DVJ-X1. The switcher can be used to either manually switch between sources by pressing the corresponding button, or automatically when using the faderstart on the audio mixer.

This video switcher accepts all video connections (component, composite and S-Video) in both PAL and NTSC formats, although the VSW-1 does not convert from one format or connection type to another for output. A Video Sync connection with the DVJ-X1 is used for a professional flicker-free video source transition.

Pioneer offers a limited one-year warranty for Pro Audio products purchased from authorized dealers.

PIONEER VIDEO SWITCHER DESIGNED FOR DJs AND VJs

VSW-1 Video Switcher is Perfect Complement to PIONEER DVJ-X1 DVD Turntable

LONG BEACH, (August 5, 2004)—Pioneer Electronics (USA) Inc. today announces its first video switcher specifically designed for DJs and VJs, helping them to meet the changing nightclub environment where great video content rivals the importance of great audio. Today's youth, having grown up with constant visual stimulation from television, video games and the Internet, expect their entertainment to have both a video and audio component. To meet those demands, many traditional audio DJs are incorporating video into their acts. PIONEER DVJ-X1 digital video turntable is one of the tools Disc Jockeys are using to become Video Jockeys.

The VSW-1 video switcher can be used with Pioneer's revolutionary DVJ-X1 to complete all of the video source switching. This eliminates the need for multiple independent devices or more than one DJ/VJ to operate the system.

The beauty of the VSW-1 is in its simplicity. The face of the unit has a red "Auto" button and two large illuminated buttons, styled after the Play / Cue buttons of the PIONEER DVJ-X1. The switcher can be used to switch manually between video sources by pressing the corresponding button. The VSW-1 also gives the DJ/VJ more freedom and flexibility in the mix with the familiar faderstart capability found in many Pioneer Pro DJ mixers and players. The DJ/VJ can automatically switch video sources when using the faderstart on the audio mixer.

This video switcher accepts multiple video connections (component, composite and S-Video) in both PAL and NTSC formats, although the VSW-1 does not convert from one format or connection type to another for output. A Video Sync connection with the PIONEER DVJ-X1 is used for a professional flicker-free video source transition.

When Pioneer Pro DJ announced the PIONEER DVJ-X1, the world's first digital video turntable, video source switching required multiple independent devices or more than one VJ to operate the system.

Incorporating the already familiar faderstart capability of Pioneer Pro DJ mixers and players, the VSW-1 gives the DJ more freedom and flexibility in the mix.

At first glance it is apparent how simple the VSW-1 really is. The face of the unit has a red "Auto" button and 2 large illuminated buttons, styled after the Play / Cue buttons of the DVJ-X1. The switcher can be used to either manually switch between sources by pressing the corresponding button, or automatically when using the faderstart on the audio mixer.

This video switcher accepts all video connections (component, composite and S-Video) in both PAL and NTSC formats, although the VSW-1 does not convert from one format or connection type to another for output. A Video Sync connection with the DVJ-X1 is used for a professional flicker-free video source transition.

Features:

General Specifications:

• Power: AC110-120 V / 220 - 240 V
• Power consumption: 9 W
• Operating temperature: + 5C° to + 35C°
• Operating humidity: 5 -85 % R.H. (without precipitation)
• Weight: 1.4 kg
• External dimensions (W x D x H): 25 x 9 x 8.6 cm

Video input section (input level/impedance)

• Component video: BNC connectors x 3 (2 systems)
• Y: 1 Vp-p / 75 Ohm
• CB/PB: 0.7 Vp-p / 75 Ohm
• CR/PR: 0.7 Vp-p / 75 Ohm
• S-Video: S connector (2 systems)
• Y: 1 Vp-p / 75 Ohm
• C: 0.286 Vp-p / 75 Ohm
• Composite video: RCA connector (2 systems) 1 Vp-p / 75 Ohm

Video output section (output level/impedance)

• Component video: BNC connectors x 3 (1 system)
• Y: 1 Vp-p / 75 Ohm
• CB/PB: 0.7 Vp-p / 75 Ohm
• CR/PR: 0.7 Vp-p / 75 Ohm
• S-Video: S connector (1 system)
• Y: 1 Vp-p / 75 Ohm
• C: 0.286 Vp-p / 75 Ohm
• Composite video: RCA connector (1 system) 1 Vp-p / 75 Ohm

Sync signal output section

• Sync output: BNC connector (2 systems) 1 Vp-p / 75 Ohm
• Supported video modulation systems: NTSC/PAL

Other connectors

• Control input: minijack (3.5 dia) 2 systems
• Control output: minijack (3.5 dia) 2 systems
