Onboard Lexicon FX processors

Soundcraft Si Expression consoles incorporate four stereo Lexicon FX processors based on the acclaimed MX400. With fully adjustable parameters and dedicated tap-tempo keys, you can tweak to your heart's content. These FX are hardware-based, so even if you're using a ton of them it doesn't affect your other processing in the slightest. All of your dynamics, EQ, filters, delays, and GEQs will always be available, no questions asked.

Say goodbye to digital mixer confusion

Soundcraft's Si Expression mixers feature a 1 Control = 1 Function interface, with each control dedicated to a single function. No confusing control layering or endless menu purgatory navigation. This approach allows the Si Expression controls to be labelled on the surface just as they would be on an analog desk. Ah, productivity - how refreshing!

It's a Soundcraft

As befitting any Soundcraft digital mixer, Si Expression boards give you extensive facilities and legendary audio quality, courtesy of the cutting-edge EMMA DSP processor, which is the same DSP platform that has helped rocket previous Soundcraft Si series consoles to stardom. With prodigious processing power, bulletproof reliability, impressive flexibility, amazing ease of use, and a surprisingly friendly price tag, Si Expression mixers are an outstanding value. Exactly what you'd expect from Soundcraft.

Soundcraft Si Expression 1 16-channel Digital Mixer Features:

• 16 mono mic inputs; 4 line inputs; AES in and out
• Color touchscreen interface
• Up to 66 input processing channels
• Pre/Post selection per input, per bus
• Global mode encoders; GEQ on every bus
• Motorized 100mm faders with FaderGlow (illuminates fader slots according to function)
• LR and C Mix busses; 4 FX busses; 8 Matrix busses; 20 sub-group / aux busses
• 4 Stereo Lexicon effects engines
• Delay on inputs and outputs; freely assignable insert loops
• Comprehensive automation with four mute groups
• Harman HiQnet integration; 64 x 64 channel option card slot
• Option cards include AES, FireWire/USB/ADAT, AVIOM, CobraNet, BSS BLU Link, Dante, optical MADI

Specifications

• Type: Digital
• Channels: 16
• Inputs - Mic Preamps: 16 x XLR
• Inputs - Line: 4 x TRS
• Outputs - Main: 2 x XLR
• Outputs - Other: 16 x XLR
• Inputs - Digital: 1 x Stereo AES/EBU (XLR)
• Outputs - Digital: 1 x Stereo AES/EBU (XLR)
• Aux Sends: 20 x Aux Sends
• Busses/Groups: 4 x Bus
• Data I/O: Harman HiQnet
• Computer Connectivity: Via Optional Firewire/USB/ADAT Card
• I/O Expansion Slots: Yes
• Faders: 16 x 100mm
• EQ Bands: 4-band
• Height: 6.7"
• Depth: 20.5"
• Width: 19"
• Weight: 24.2 lbs.
