Mid-Morph equalization on every input

The very best mixers allow audio to be precisely tuned to a particular environment by using sophisticated equalization. Every one of the UNITY DR16's inputs is loaded with Peavey's Mid-Morph equalization, which is actually two EQ controls in one. When the knob is cut, it pulls out low-mid frequencies that muddy the sound. When boosted, it shifts to an upper-mid frequency that brightens the vocal range. Mid-Morph can enhance vocal or music clarity and eliminate the boominess that may result from less-than-perfect room acoustics.

Convenient wireless connectivity

Features

• 16-input digital mixer with 8 world-class Silencer preamps
• Mid-Morph EQ on each input tailors your mix to any environment
• Priority ducker for applications that require public speaking and background music
• Group mute and solo channels make mixing easier
• 2 assignable feedback eliminators prevent unwanted screeching and squealing
• 4 effects processors and advanced reverb algorithms for polishing your sound
• Ethernet and Wi-Fi connectivity enable remote operation and more
• Parametric EQ, 31-band graphic EQ in cascade, and auto feedback eliminator on every output
• Extension card slot allows you to use channels 13-16 as analog inputs, S/PDIF, or Dante (4 x 1/4" card is pre-installed)

Specifications:

• Type: Digital Rackmount Mixer
• Channels: 16
• Inputs - Mic Preamps: 8 x XLR-1/4" combo
• Phantom Power: 8 channels
• Inputs - Line: 4 x 1/4"
• Inputs - Other: 2 x 1/4" (Hi-Z)
• Outputs - Main: 2 x XLR (main)
• Outputs - Other: 2 x XLR (monitor)
• Aux Sends: 2 x XLR
• Busses/Groups: 4 x Aux bus
• Data I/O: USB, Ethernet, Wi-Fi
• USB: 1 x Type A (2-track record/playback)
• Wi-Fi (Peavey Remote App), Ethernet (networking)
• I/O Expansion Slots: Extension card slot (Dante, S/PDIF), Expansion card option (linking multiple units)
• Headphones: 1 x 1/4" TRS
• EQ Bands: Mid-Morph EQ, Parametric EQ, 31-band Graphic, High/Low Pass Filters
• Effects: Reverb algorithms, Delay, Chorus, Flanger, Phaser
• Signal Processing: Dynamic Loudness, RMS Compressor, Feedback Eliminator
• Storage: USB stick
• Software: Peavey Remote Control App (iOS)
• Rackmountable: Yes, 2U
• Power Source: Standard IEC AC cable
