Midas M32 40-Input 25-Bus Digital Mixer

Midas M32IP 40-Input Digital Mixer

A close look at M32 reveals that the styling is completely new in every sense of the word. Rajesh Kutty's automotive-inspired design elements mesh perfectly with a recognisable MIDAS signature, setting the M32 apart from any other console. Its beautifully streamlined and elegant form factor completely revolutionises the experience of live mixing.

The MIDAS M32 construction is equally impressive, and is designed to offer you years of reliable performance while withstanding the demanding environment of live performance venues. M32 employs a predominantly space-frame construction, with parts of the sub-frame consisting of durable and lightweight carbon fibre and aluminium. Multiple alloys have been employed throughout to guarantee maximum component efficiency and an improved performance-to-weight ratio.

Industry-Leading 192 kHz Precision

The groundbreaking M32 console combines legendary MIDAS sound quality with advanced digital technology, future-proof 96 kHz capable open architecture design and industry-leading 192 kHz ADC and DAC converters, creating a revolutionary mid-format live console. M32 features ultra-sleek styling, offering you a truly luxurious mixing experience. High-end construction materials including carbon fibre provide unparalleled durability and strength, plus substantially lower weight than comparable consoles.

The M32 utilises award-winning MIDAS PRO Series microphone preamplifiers and the custom-designed MIDAS PRO motorised faders that are rated for 1 million life cycles-three times more than other leading consoles.

Legendary MIDAS Sound Quality

While the MIDAS M32 design, styling, and construction will surely turn a lot of heads, it's the sound that matters most to engineers and performing artists. And that's where M32 shines even brighter - as the latest in a long line of pristine-sounding MIDAS consoles, it descends from a celebrated lineage that literally set the standard in electrical design and sound quality. Ever since MIDAS consoles first found fame 40 years ago with acts like Billy Joel, Yes, The Beach Boys, Pink Floyd and others, the MIDAS legacy has always been about uncompromising quality and the ultimate in sound reproduction.

Backing the analogue input section are audiophile Cirrus Logic multi-channel 192 kHz capable A/D converters, which boast a 114 dB dynamic range, ensuring impressively low distortion and low noise performance.

Channel Strip

The M32 Channel Strip puts the most important channel processing parameters into one section so that no matter which channel you are working on, the controls are always the same. Illuminated rotary encoders and switches give you control of preamp settings, frequency shelving, dual dynamics sections, as well as multi-mode fully parametric EQ, bus sends, main, mono and stereo panning.

Sends On Fader

M32 brings the convenience of digital mixing to your Aux and output bus mixes too, thanks to its integrated Sends on Fader feature. This incredible function allows you to build powerful, dedicated sub-mixes for monitor, secondary zone feeds, and much more - all without affecting the front of house mix or levels.

The M32 allows you to send your choice of signals to any Aux or output bus and then dial in the perfect mix via the channel faders.

The console remembers where you set the faders and instantly recalls them when you select a bus for quick adjustments.

"Acoustic Integration" - the Live Sound Revolution

Legendary 40-year old British company TURBOSOUND, famous for producing some of the world's best speaker systems, have teamed up with MIDAS to seamlessly integrate mixer and speaker systems. They call it "Acoustic Integration".

The M32's ULTRANET bus allows streaming up to 16 channels of pristine digital audio to an array of TURBOSOUND iQ speakers - all on a single CAT5 cable, along with control data to set sound presets remotely.

100-Band RTA for all Channel/Bus EQ's

The M32 now includes a high-resolution 100-band Real Time Analyzer (RTA), with full Bar and Spectrograph views. This high-resolution RTA displays the audio energy distribution in 100 frequency bands over time - capturing a sonogram window of a full 10 seconds.

Switch between the Large RTA view, displaying any available signal in full screen resolution, or the Combined view with the RTA view shown above each of the channel and bus EQ curves. See the results of your filtering choices in the audio spectrum directly. Additionally, the RTA can be displayed on top of the 31-band graphic EQs in the FX rack.

16 Breathtaking FX "Plug-Ins" Based on True Physical Modeling

They've added 16 breathtaking FX "Plug-Ins" to the M32, giving you access to a total of 50+ effects that would otherwise cost tens of thousands of dollars in hardware.

This new generation of high-end FX "Plug-Ins" is based on True Physical Modeling of classic audio hardware. They essentially "rebuilt" classic analog gear in the digital domain and included models of legendary processors such as Urei's 1176*, Teletronix LA-2A* and Fairchild 670* compressors as well as the legendary Pultec* EQP-1a and EQ5 equalizers etc. They also added a cutting-edge 5-band multiband compressor.

Last but not least, the M32 can now run 4 studio-quality stereo reverbs together with 8 channels of 31-band graphic EQ. This allows you to replace your old outboard gear with a fully recallable onboard solution.

Gain Splitting and Remote Control for FOH and Monitoring

A new Gain Split mode separates channel gain (trim) from the head amp gain, allowing both the FOH and/or the monitor engineer to adjust local trim digitally - and independently of the preamp gain.

Additionally, the new HA Gain Remote option allows console gains to be remotely controlled by an external console, such as when using the M32 as a stage box.

LCD Scribble Strips

A total of 29 programmable LCD Scribble Strips offer channel/bus identification that mirrors what is being controlled.

Use them to enter input/output tags, plus add icons you recognize at-a-glance. Then assign colors to create visual groups for immediate, on-the-fly recognition of similar inputs.

Virtual Effects Racks

M32 includes an extensive array of onboard effects, rendering outboard processing racks a thing of the past. The Virtual FX rack features 8 true-stereo, studio-grade effects engines each assignable to any input, group or output mix bus. Choose from high-end FX modules including a range of reverbs, delays, EQs, dynamics and much more.

Each FX algorithm has been completely re-imagined for stunning performance - typically costing several times the price of the M32.

Custom-designed, and physically modeled after some of the most iconic and sought-after processors, all effects run inside the low-latency environment of the M32 mix engine, ensuring flawless performance, flexible routing and the end of cable faults forever!

Features:

• Live performance and studio recording digital console with up to 40 simultaneous input channels
• 32 award-winning MIDAS microphone preamplifiers
• 25 time-aligned and phase-coherent mix buses
• AES50 networking allows up to 96 inputs and 96 outputs
• Open architecture allows for future 96 kHz operation
• 192 kHz ADC and DAC converters for outstanding audio performance
• Industry-leading design by Bentley* Motors Designer
• High-performance carbon fibre, aluminium and high-impact steel structure
• MIDAS PRO FADERS are rated for up to 1,000,000 cycles - three times that of other leading manufacturers.
• 40 bit floating point digital signal processing
• 8 DCA and 6 mute groups
• 8 stereo signal processing effects engines
• 25 MIDAS PRO motorised 100 mm faders
• Daylight viewable 7" full colour TFT display screen
• 32 x 32 channel USB 2.0 audio interface
• DAW remote control emulations of Mackie Control* and HUI* protocols
• Optional wireless remote control with MIDAS Apps for iPhone* and iPad*
• Auto-ranging universal switch-mode power supply
• Designed and engineered in England
