Chauvet DJ EVE P-150 UV

Description

Designed for mobile lighting professionals, the CHAUVET DJ EVE P-150 UV is a 150W LED black light cannon with forty UV (ultraviolet) diodes. Featuring two interchangeable magnetic lenses used to alter the fixture's beam angles to either 25, 35, or 45°, it provides wide ultraviolet washes that enhance the appearance of white or fluorescent colors with a supernatural glow, ideal for clubs, performance stages, theatrical productions, or special-effects installations.

The EVE P-150 UV allows for both wired and wireless operation in either standalone or DMX-controlled configurations. Plug a D-Fi USB transceiver (available separately) into the fixture's USB port and pair with a D-Fi-enabled controller for instant wireless DMX communication, or use a standard 3-pin/5-pin DMX cable for a wired connection. Two DMX channel modes enable varying levels of control over the fixture. For operation without a DMX controller, use the built-in programs in either Sound-Active or automatic mode. You can even synchronize multiple units via Master/Slave control, to create coordinated light shows. Additional controls include an on-board menu with digital display and the IRC-6 wireless remote (available separately).

Other features include flicker-free and silent operation for video applications, an auto-sensing power supply, and pass-through powerCON I/O to connect a single power cable to the wall and daisy-chain up to 9 units at 120V, or up to 16 units at 230V. Housed in a cast-aluminum enclosure that provides extra strength without the weight, the EVE P-150 UV comes equipped with a dual-yoke bracket that can be used for conventional mounting to a truss or lighting stand, or to create a variable-angle floor stand. The fixture ships with a gel frame.

Highlights

• Robust LED black light cannon designed for mobile lighting professionals
• 40 x UV LEDs, 150W total
• Included interchangeable magnetic lenses alter the beam to desired angles
• 25, 35, or 45° beam angles
• 2 x DMX channel modes
• USB port lets you plug the D-Fi USB transceiver (available separately), for wireless Master/Slave or DMX control
• Standalone or Master/Slave configuration
• Built-in automated programs, sound-activated
• LED strobe effect
• Variable electronic dimmer: 0-100%
• Daisy-chain power for up to 8 units at 120V, or 16 units at 230V
• Multi-voltage operation: 100-240 VAC, auto-ranging
• powerCON connectors for secure power connections and power linking
• LED display with 4-button menu for easy navigation
• 3- and 5-pin DMX I/O
• Flicker-free and silent operation for video applications
• Cast-aluminum housing provides extra strength without the weight
• Double-bracket yoke can be used for conventional mounting or as a variable-angle floor stand
• Compatible with IRC-6 wireless remote (available separately)
• Built-in gel frame holder and 6.25" accessory slot to hold barn doors
• Includes gel frame

Specifications:

• Light Source
  • 40 x 3.75 W UV (ultraviolet) LEDs
  • Total Power: 150 W
  • Current: 2 A
  • Life Expectancy: 50,000 hours
• Wavelength : 395 nm
• PWM Frequency : 2 kHz
• Beam Angle : 25, 35 (no lens), or 45°
• Operating Modes
  • DMX
  • Master/Slave
  • Standalone
• Effects
  • Electronic Dimming: 0-100%, with dimming curves
  • Auto Programs
  • Sound-Active
  • Color macros
  • Strobe: Variable from 0 to 34 Hz
• DMX Interface DMX Channels Modes: 1 or 5
• DMX Connectors : 3-pin XLR, in/out, 5-pin XLR, in/out
• Wireless Control : D-Fi USB transceiver (available separately), IRC-6 remote (available separately)
• Manual Controls : 4-character LED display, 4-button control interface
• Power Linking : 8 units at 120 V, 16 units at 230 V
• Power Requirements : 100-240 VAC, 50/60 Hz (auto-ranging)
• Power Connectors : Input: 1 x powerCON, Output: 1 x powerCON
• Power and Current : 120 V (60 Hz): 111 W, 0.9 A, 230 V (50 Hz): 111 W, 0.5 A
• Cooling : Fanless
• Housing : Cast aluminum
• Mounting : Double-bracket yoke
• Approvals : CE, MET
• Dimensions : 8.6 x 9.65 x 12" / 220 x 245 x 305 mm
• Weight : 7.6 lb / 3.5 kg
• Package Weight : 9.86 lb
• Box Dimensions (LxWxH) : 13.8 x 11.8 x 9.2"
