Features

• Extremely bright, 180 W LED moving head spot designed for large events
• Dual gobo wheels allow for gobo morphing and amazing mid-air projections
• Motorized zoom for short- or long-throw situations
• Beams always remain on the dance floor using the built-in, innovative Totem mode
• Split the beam and cover a larger area with the 3-facet prism
• Emit crisp projections at almost any distance using the motorized focus
• Quickly and easily change gobos using the easy-access gobo door
• Convenient, wireless non-DMX control using the optional IRC-6 remote
• Set, save, and recall 1 scene manually directly from the full-color LCD display

• Save time running cables by power linking multiple units
• Fits best in the CHS-50 VIP Gear Bag
• DMX Channels: 10 or 16
• DMX Connectors: 3-pin XLR
• Pan and Tilt: 540°/240°
• Pan and Tilt Ranges: 180°, 360°, 540° pan/90°, 180°, 240° tilt
• Colors: 7 + white, split colors, continuous scroll at variable speeds
• Gobo wheel (1): 7 + open (6 metal + 1 glass), rotating, interchangeable, slot-n-lock, continuous scroll at variable speeds
• Gobo wheel (2): 8 + open (8 stamped), continuous scroll at variable speeds
• Gobo Size: 26.8 mm outside, 22 mm image, 1 mm max thickness
• Light Source: 1 LED (white) 180 W (48.1 A), 50,000 hours life expectancy
• Strobe Rate: 0 to 15 Hz
• PWM Frequency: 1,000 Hz
• Zoom Angle (motorized): 13° to 28°
• Illuminance (13°): 38,200 @ 2 m
• Illuminance (28°): 8,720 lux @ 2 m
• Power Linking: 2 units @ 120 V; 5 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 327 W, 2.9 A @ 120 V, 60 Hz
• Power and Current: 304 W, 1.5 A @ 230 V, 50 Hz
• Weight: 42.2 lb (19.2 kg)
• Size: 16.6 x 11.9 x 20.5 in (423 x 303 x 520 mm)
• Optional Controllers: IRC-6

• Approvals: CE
