ADJ Vizi Beam CMY

The ADJ Lighting Vizi Beam CMY is a high-performance moving head beam fixture that features a 310W Osram Sirius HRI discharge lamp, CMY color mixing and a wealth of advanced features for the modern lighting professional.

Specification

Light Source:

• OSRAM Sirius HRI 310W PRO Discharge Lamp (6,000 hr.)
• Color temperature: 7850K (+/- 500K)
• CRI: 86 (+/- 5)

Features:

• CMY Color Mixing
• On-Board Wireless DMX
• Motorized Focus + 16-bit fine focus
• 2-degree beam angle
• Frost Filter to create wash effect
• High quality glass lens
• 2 Rotating prisms:
• 0-100% smooth dimming
• Pan/Tilt locks
• Various strobe speeds
• OTA, wireless, firmware updates
• Fan cooled

Color Wheel:

• 14 dichroic colors + white (Includes CTO (3200K), CTB (9000k) & UV)
• Indexable color wheel for split colors
• Separate Multi-Color Effect

GOBO Wheel:

• 17 static GOBOs + open (4 GOBOs are beam reducers)
• GOBO Shake Effect

Prism Wheels:

• 2 Rotating prisms
• 16 facet circular and 6 facet linear prisms
• Prisms Overlay

Control:

• Protocols: DMX512 & RDM
• Control Mode: DMX512 & Manual (On-board Controls)
• 2 DMX Channel Modes: 20/24 Channels
• Color LCD display with 4-button function menu
• 0-100% smooth dimming
• Various strobe speeds
• With Wired Digital Communication Network

Pan/Tilt:

• Pan: 540 degrees (plus 16-bit fine pan)
• Tilt: 270 degrees (plus 16-bit fine tilt)
• 3 Phase, High Speed, Pan/Tilt motors

Connections:

• DMX Connections: 5-pin DMX In/Out (Data link max: 32 fixtures)
• Power Connections: Outdoor locking In/Out connections to daisy chain power

Electrical:

• Multi-voltage operation: 100-240V, 50/60Hz
• Max power consumption: 410W (@120V), 390W (@230V)
• Fuze Protected: 6.5A

Dimensions & Weight:

• Dimension: 9.8" (L) x 14.3" (W) x 17.9" (H) / 248 x 364 x 454.8mm
• Weight: 38.5 lbs. / 17.5 kg.

Approvals / Ratings

• CE
• cETLus (Pending)

What's Included:

• 2x Omega Brackets (107 Type)
• 2M, outdoor locking 14AWG power cord
