Chauvet DJ EVE E-50Z (White Housing)

Overview

The white EVE E-50Z 50W LED Ellipsoidal from Chauvet DJ is a lighting fixture designed to shine a hard-edged, warm white spotlight for mobile and permanent installations. It features D-Fi USB compatibility for wireless Master/Slave or DMX control and is equipped with manual zoom for flexibility to project from any distance.

The lighting fixture's framing shutters let you alter and control the projected beam. The EVE E-50Z fixture includes holders for glass and steel gobos as well as a gel frame. It can operate in standalone mode, which eliminates the need for DMX control, and you can save time running extension cords by power-linking multiple units together.

Features

• LED Ellipsoidal shines a hard-edged, warm white spot in any direction.
• Easily highlight areas by altering the projected beam with framing shutters.
• Flexibility to project from any distance using the manual zoom.
• D-Fi USB compatibility for wireless Master/Slave or DMX control.
• Flicker-free operation suitable for on-camera use.
• Includes holders for glass and steel gobos and a gel frame.
• Save time running extension cords by power linking multiple units.
• Eliminate the need for DMX control with standalone operation.

Specifications:

• DMX Channels : 1 or 3
• DMX Connectors : 3-pin XLR
• Light Source : 1 x LED (warm white) 50 W, (1.3 A), 50,000 hours life expectancy
• Strobe Rate : 0 to 29 Hz
• PWM Frequency : 1.2 kHz
• Illuminance : 20°: 7,910 lux at 2 m, 39°: 2,710 lux at 2 m
• Power Linking : 16 units at 120 V, 26 units at 230 V
• Input Voltage : 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current : 59 W, 0.5 A at 120 V, 60 Hz, 63 W, 0.3 A at 230 V, 50 Hz
• Gobo Size : Outside: 53.3 mm, Image: 43 mm, Max Thickness: 2 mm
• Zoom Angle : Manual: 20 to 39°
• Approvals : CE and MET
• Color Temperature : 3500K
• Gel Frame Holder : 5.5" (14 cm)
• Controllers : D-Fi USB
• CRI : 81
• Dimensions (L x H x D) : 18.9 x 6.2 x 15" (480 x 157 x 381 mm)
• Weight : 9.2 lb (4.2 kg)

Packaging Info

• Package Weight : 14.3 lb
• Box Dimensions (LxWxH) : 25 x 11.8 x 11.8"
