Elation Compu 1024EC

Description

Compu 1024EC was developed to be the simplest solution to operating your lighting effects. With other lighting consoles you have an array of faders, buttons and knobs to work with – remembering what they all do can get tricky. The advantage with a PC based system is the ability to see everything right in front of you.

Compu 1024EC features include: a vivid display of scenes and shows; the ability to name and rename all of your cues; plus have direct access to your colors and gobos.

Compu 1024EC has all the features for the professional lighting programmer but developed with the novice in mind, taking away fears and doubts about programming lighting.

Features:

• ?Complete Package includes:
  CD-Rom Bundle Software
  USB to DMX Interface (dongle)
  2.0 USB cable
  User Manual
• Compu 1024EC Main features
  • 512 DMX channels per interface
  • Maximum 512 DMX channels (to run more than 512 channels you must purchase more Compu Pro version dongles)
• Master Scene Page
  • +2 Art-Net Universes (Ethernet Out)
  • Unlimited number of Scenes!
  • Unlimited number of Cycles! (Shows)
  • Fixtures only limited to channels used
  • Pre generated movements and shapes
  • Live control button
  • Easy View (Limited 3D Offline visualizer)
  • Large Library of Fixture profiles
  • Easy Library Creator
• Control features:
  • Hot key triggering (using keyboard)
  • Touch Screen Ready!
  • Multi media triggering! Plays MP3's
  • DMX triggering
  • DMX-IN
• Triggering by Midi in (Midi Notes)
  • Audio Input
  • Easy to use Electronic Racks
  • easy step - to program chases
  • chaser - built in chases
  • sequencer - built in sequencer
  • x-fader - built in cross-fades
  • follow spot - XY following
• USB interface (dongle) Technical Specs & Data:
  • 3 Pin XLR out only
  • Polarity (2-, 3+)
  • I/O ports
  • Power by USB
  • Optional external power: 9-12v DC
  • Dimensions: 3.5" x 3" x 1.5"
  • Weight: .2 lbs
  • Can be used as stand alone device
  • 96kb recording memory
• CD-Rom bundle includes:
  Compu 06 software
  Compu 04 software
  Compu 02 software
  Easy Stand alone software
  Magic 3D easy view software
  DMX to USB interface drivers
• Minimum System Requirements:
  • Laptop or desktop computer with USB port
  • Windows ME, XP or any up-to-date version
  • 800x600 screen resolution
  • 256Mb Memory
  • Clock frequency: 800 MHz
  • 32Mb RAM video card to use the "3D software" supporting Microsoft DirectX 9.0
• Best Performance System Requirements:
  • Laptop or desktop computer with USB port
  • Windows XP or any up-to-date version
  • 1280x1024 screen resolution
  • 512Mb Memory
  • Clock frequency: 1.5 GHz
  • 128Mb RAM video card to use the "3D software" supporting Microsoft DirectX 9.0
• For Compu Live Support, please call 866-245-6726 extension 548.
• For use with windows XP or ME only.?
