New Sound Bank
A new sound library has been created for the JUNO-Gi, with over 1,300 factory selections that cover a universe of instrument types and musical styles. Tone Category buttons help you scan the vast library and locate the perfect sound with ease and speed. New to the JUNO-Gi are Live Sets, which comprise up to four layered tones each — create your own unique sounds by stacking and/or splitting tones and saving them together as a Live Set. Furthermore, a Special Live Set section takes maximum advantage of the JUNO-Gi sound engine for the most advanced synth sounds.
Performance and Portability
The JUNO-Gi has been designed with the performer in mind. It provides supreme mobility thanks to its lightweight body and battery-power compatibility (up to three hours of continuous operation with eight NiMH AA batteries), letting you experience the freedom of performance in any environment. Roland’s battery-powered amps such as the BA-330 and KC-110 are perfect companions for the JUNO-Gi during street performances. Performers will also appreciate the JUNO-Gi’s friendly front panel, which is covered with hands-on controls, clearly marked and easy to reach. The enlarged 240x64 graphic LCD provides clear visibility and fast navigation, even on outdoor gigs with troublesome sun glare.

Digital Recording & FX
Pro recording onboard! The JUNO-Gi’s built-in eight-track digital recorder with 64 virtual tracks provides a full-featured multitrack studio environment, complete with dedicated transport controls and mix faders. The recording media is a removable SD or SDHC card, with up to 192 hours of recording time possible when using a single 32GB SDHC card! Also supported is full import and export of track data with a computer. The same pro performance effects found in the BOSS GT series are built into the JUNO-Gi, as well as effects designed for vocal processing. Connect a guitar or microphone directly and apply these top-quality effects for instant CD-quality sound as you record.

USB MIDI & Audio
The JUNO-Gi’s multifunction USB port offers both audio and MIDI functionality — a one-cable connection to your computer is all you need to stream audio and MIDI back and forth and interface with your favorite music software. When you combine the JUNO-Gi with the bundled Cakewalk Sonar LE 8.5 software, you have a complete digital audio workstation package for your PC. In addition, the MIDI Controller Mode lets you operate the JUNO-Gi as a MIDI master keyboard for controlling your DAW or external MIDI devices.



Keyboard

61 keys (with velocity)

Maximum Polyphony

128 voices

Parts

Live Set (4 layers) + 16 parts

Wave Memory

128 MB (16-bit linear equivalent)

Preset Memory

Live Set: 1,379
Tone: 788 + 256 (GM2)
Rhythm Set: 14 + 9 (GM2)

User Memory

Live Set: 256
Favorite: 100

Effects

Multi-Effects: 2 systems, 79 types
Chorus: 3 types
Reverb: 5 types

Digital Recorder Section

Tracks

Track: 8
V-Track: 64 (8 V-Tracks per each Track)
* Up to 2 tracks can be recorded simultaneously, and up to 8 tracks can be played back simultaneously.

Maximum Number of Songs

99

Memory Capacity

SD memory card: supports SDHC cards to a maximum of 32 GB

Sample Rate

44.1 kHz

Recording Time (conversion in one track)

Card Capacity Recording Times
1 GB Approx. 6 hours
2 GB Approx. 12 hours
4 GB Approx. 24 hours
8 GB Approx. 48 hours
16 GB Approx. 96 hours
32 GB Approx. 192 hours
- The maximum recording time (storage used) for one song is approximately 12 hours (2 GB).
- The above recording times are approximate.
- The above recording times are for when only one track is used.
For example, if you record using all eight tracks, the available time for each track will be one eighth of the time listed.
- Since the 2 GB SD card included with the JUNO-Gi contains a demo song, the available recording time will be shorter than listed above.
* With the Track Export function, a maximum of approximately 6 hours and 40 minutes worth of monaural data (approximately 3 hours and 20 minutes worth of stereo data) can be output.

Nominal Input Level

LINE INPUT jacks: -10 dBu
GUITAR/MIC INPUT jack:
GUITAR: -20 dBu
MIC: -40 dBu

Effects

Insert Effects: 3 banks (Guitar, Mic, Line)
Mastering Tool Kit
Reverb

USB Memory Song Player Section

File Format

Audio File: WAV, AIFF, MP3
Standard MIDI File: format-0/1

Number of Songs

99 Songs

External Memory

USB MEMORY (supports USB 2.0 Hi-Speed Flash Memory: Sold Separately)

Rhythm Pattern

Preset: 371
User: 99
Song (Digital Recorder): 99

Arpeggiator

Preset: 128
User: 64

Chord Memory

Preset: 17

Controllers

Pitch Bend/Modulation Lever
D Beam Controller
S1/S2 Buttons
Sound Modify Knob x 6

Display

240 x 64 dots graphic LCD (with backlit)

External Memory

SD/SDHC Card

Connectors

OUTPUT Jacks (L/MONO, R) (1/4 inch phone type)
PHONES Jack (stereo 1/4 inch phone type)
SONG/CLICK OUT Jack (stereo 1/4 inch phone type)
LINE INPUT Jacks (L, R) (1/4 inch phone type)
GUITAR/MIC INPUT Jack:
MIC: 1/4 inch phone type or XLR type (phantom power), GUITAR: 1/4 inch phone type (Hi-Z)
CONTROL PEDAL Jack
HOLD PEDAL Jack
MIDI Connectors (IN, OUT)
USB COMPUTER Connectors (USB Hi-Speed Audio/MIDI)
(Use a USB cable and a computer with a USB connector that support USB 2.0 Hi-Speed.)
DC IN Jack

Power Supply

DC 9 V
(AC Adaptor or Rechargeable Ni-MH Battery (AA, HR6; sold separately) x 8)
* Carbon-zinc batteries or alkaline batteries cannot be used.

Current Draw

750 mA

Battery Life for Continuous Use

Rechargeable Ni-MH batteries (AA, HR6): Approximately 3 hours (approximately 2 hours if USB memory is connected) (This figure will vary depending on the actual conditions of use.)

Accessories

Owner's Manual
Quick Guide
CD-ROM (USB Driver)
DVD-ROM (Cakewalk PPP)
SD Card (2 GB, installed in the JUNO-Gi when shipped from the factory)
SD Card Protector (installed in the JUNO-Gi when shipped from the factory)
USB Memory Protector
AC Adaptor
Power Cord

Options

Keyboard Stand: KS-18Z
Pedal Switch: DP Series
Expression Pedal: EV-5
USB Memory
* Use USB memory sold by Roland. We cannot guarantee operation if other products are used.

Size and Weight

Width

1,008 mm
39-11/16 inches

Depth

300 mm
11-13/16 inches

Height

105 mm
4-3/16 inches

Weight

5.7 kg
12 lbs. 10 oz.
