INTUITIVE LAYOUT

Designed to deliver the tightest possible integration and fast response with rekordbox dj, this controller mirrors the software's layout to give you effortless control. Hit the 16 back-lit rubber Performance Pads to instantly trigger quantized Hot Cues, Slicer and Pad FX.

ADVANCED FX

Pad FX lets you create multiple FX chains using all 16 pads, while the Sequencer mode allows you to record, play and loop sample sequences on the fly. Trigger up to three of rekordbox dj's quantized Beat FX and twist the dial to manipulate the parameters of each.

Plus you can release complex FX patterns with a vinyl brake, echo or back spin.

LARGE ALUMINIUM JOGS

The DDJ-RZ's full-sized jog wheels are optimised for a perfect scratch response and you can use Jog Feeling Adjust to set your preferred resistance. The jogs have illuminated cue point markers and an accurate countdown for even greater precision.

SOUND COLOR FX

This controller comes with four preset Sound Color FX buttons - Space, Jet, Pitch and Filter - which you'll be able to customise in the future with upcoming rekordbox dj Plus Packs.

OSC SAMPLER

Use the new oscillator sampler to overlay four pre-set sounds - Noise, Sine, Siren and Horn - and modulate the output using the dial. The sampler also gives you the freedom to trigger and manipulate your own samples loaded to the banks in rekordbox dj.

SEQUENCER

Record, play and loop pad routines on the fly.

Dual USB port

The two soundcards and USB ports (with a simple A/B-switch) enable you to hook-up two computers at the same time for seamless DJ transitions.

Magvel Fader

Our own Magvel Faders account for smooth and steady control. Two metal shafts support the fader knobs, while the contact-free magnetic system is designed to endure millions of performances.

Needle search

Needle search provides a touch strip for intuitive and fast searches.

Slip Mode

Keep tracks playing muted during live edits such as loop, scratch or reverse. Release the jog wheel and the track comes back at exactly the right place.

Release FX

Seamlessly exit complex FX patterns by selecting vinyl brake, echo or back spin and twisting the dial.

Well connected

The DDJ-RZ has 6 inputs for ultimate flexibility to connect to CDJs or analogue turntables and use as a stand-alone mixer. You can also connect directly to professional PA equipment thanks to a Booth and 2 Master, plus the 2 MIC inputs have been improved to eliminate distortion.

Clear and powerful sound

A Wolfson high-performance D/A converter and low-jitter crystal oscillator ensure a faithful reproduction of sound sources and deliver a clear, powerful club sound.

Main Features

• P-LOCK Fader Cap
• Magnetic Crossfaders
• Plug and Play
• Auto Standby
• rekordbox dj Software Included
• Software System Requirements
• Windows 10/ 8/ 8 Pro/ 8.1 Pro (latest service pack)/ 7/ Home Premium/ Professional/ Ultimate (latest service pack)
  (CPU) Intel® Processer Core i3, i5 or i7, (Memory) 4GB or more
• Mac OS X 10.10/ 10.9/ 10.8 (latest version)
  (CPU) Intel® Processer Dual Core 2.0 GHz or higher, (Memory) 4GB or more
• Display Resolution: 1280 x 768 or higher
• Dimensions (WxHxD): 34.25" x 3.88" x 15.62 (870 mm x 98.4 mm x 419.5 mm)
• Weight: 23.6 lbs (10.7 kg)
• Soundcard: 24 bit/44.1 kHz
• Frequency Range: 20 - 20,000 Hz
• Signal-to-Noise Ratio: 111 dB
• Distortion: < 0.002 % (USB)
• Power Requirements: 220-240 V / 50/60 Hz

Performance Control

• Channels: 4
• Deck Control: 4 / Dual
• Jog Wheel: 8" (202 mm) durable aluminium jog wheel
• Feeling Adjust: Yes
• Pad FX: Yes
• Filter: High & Low Pass filter
• Colour FX: Filter, Jet, Pitch, Space
• Release FX: Back spin, Echo, Vinyl brake
• FX Parameters: 3knob x 3button
• Sampler: 16slot x 4bank
• Oscillator Sampler: Horn, Noise, Sine, Siren
• Hot Cues: 8
• Sequencer: Yes
• Manual Loop: Yes
• Auto Beat Loop: Yes
• Beat Jump: Yes
• Slip Mode: Yes
• Needle Search: Yes
• Talkover Function: Yes
• EQ Isolator: Yes

Fader

• Fader Start: Yes
• Crossfader Curve Adjust: Yes

Terminals

• Inputs: 2 PHONO/LINE (RCA), 4 CD/LINE (RCA), 2 MIC (XLR/Jack Combo, 1/4 inch Jack)
• Outputs: 1 BOOTH (1/4 inch Jack), 2 HEADPHONE MONITOR (1/4 inch Jack, MiniPin), 2 MASTER (XLR, RCA)
• USB: 2 USB B ports
