Regular
Price $2999.99
Our Price $1999.99

|
The MATRIX 2000 is a complete sound reinforcement solution consisting of two 12” two-way speakers and an 18” subwoofer, equipped with a built-in 1200-watt three-channel amplifier. The three-channel amplifier houses all the electronics required to run the system including electronic crossovers, equalization and compressors. The electronic circuity is fine tuned to match all of the components for the best possible sound.
The MATRIX 2000 is designed for easy operation, as you do not need to tweak frequencies or finesse levels. To set-up the system’s components, simply connect the XLR right and left signal cables, speaker cables and power cord and you’re ready to go! |
12” TWO-WAY SPEAKERS:
The 12” two-way speakers are loaded with B-52 custom designed 12” loudspeakers and 1“ titanium diaphragm compression drivers, mounted to 900 x 400 constant directivity horns. The speakers are designed to be pole mounted, sit as stage monitors and have built-in (3/8” – 16 TPI) flying hardware for permanent installations. The front panel of the two-way speakers are convex so as to fit perfectly on to the subwoofer’s front grille. Each two-way speaker has the power handling capability of 300 watts and a nominal impedance of 4 ohms. |  |
|
|
 |
BUILT-IN 3-CHANNEL AMPLIFIER
The 18” subwoofer enclosure is divided into two separate compartments. The front chamber serves as the cabinet for the cast-framed, 4” voice coil, 18” subwoofer. The rear chamber houses all of the system’s electronic circuitry, which includes the amplification for all three components, power supply, compressor and preamps. The 18” subwoofer has a power handling
capability of 600 watts and a nominal impedance of 8 ohms. |
| |
TRANPORTING THE SYSTEM:
Move the subwoofer onto its casters and place the included cover over the subwoofer. Next, pull the included covers over the satellite speakers and close the zippers. It is recommended that you transport the subwoofer and satellites separately. You may transport all the components at the same time by placing the satellite speakers onto the subwoofer’s front panel facing down. Secure the satellite speakers to the subwoofer with the included locking strap by fastening it to the bar handles on the side
of the subwoofer cabinet. |  |
1200-WATT 3-CHANNEL AMPLIFIER
|
Subwoofer Power Output:
12" Two-Way Power Output:
Line in:
Parallel out:
Input Impedance:
Speaker Out:
Power Requirement:
Crossover Frequency: |
600 W / 8 Ohms
2 x 300 W / 4 Ohms
XLR Female
XLR Male
48 k Ohms
Speakon NL4 Style Connector
115V<>50/60Hz<>10A
230V<>50/60Hz<>5A
120 Hz; 24 dB/ Octave |
|
18" SUBWOOFER
|
Speaker:
Nominal Impedance:
Subwoofer Freq. Response:
Sound Pressure Level (1w/1m):
Maximum SPL:
Weight:
Dimensions (Transport): |
1 x 18" Cast-Framed, 4" Voice Coil
Custom Subwoofer
8 Ohms
30 - 120 Hz
129 dB
130 dB
160 lbs
35" (H) x 28" (W) x 23" (D) |
|
12' TWO-WAY SPEAKERS
|
Speaker Input:
Loudspeaker:
Compression Driver: HF Dispersion: Nominal Impedance:
Active Freq. Response:
Crossover Frequency (passive):
Maximum SPL:
Weight:
Dimensions (Upright): |
Speakon style connector
(pin 1+ = +, pin 1- = -)
12î Custom Built B-52 Transducer
1î Exit Titanium Diaphragm on Constant Directivity Horn
90 x 40
4 Ohms
120 ‚ 20K Hz
2K Hz 12 dB/Octave
126 dB
40 lbs.
23î (H) x 14î (W) x 13î (D) |
|
|
| |
